Chain Geared Beam Trolley / Gear Travel Trolley

H-Lift Chain Geared Beam Trolley / Gear Travel Trolley (GT-C Type)

- Capacity of geared trolley: 1t~10t
- The standard operating length: 3m; The other length is available.
- Adjustable beam width (standard) of geared trolley: 64mm~203mm
- Adjustable beam width (extra long) of geared trolley: 102mm~305mm
- Adjustable to any beam width, simply by adjusting the number of collars.
- The wheels are made to fit any shape of beam
- High grade sealed ball bearings.
- With anti-drop plates.

Model			GTFA005	GTFA010	GTFA020	GTFA030	GTFA050
Capacity (t)			0.5t x 3m	1t x 3m	2t x 3m	3t x 3m	5t x 3m
Proof Load (kN)			7.35	14.7	29.4	44.1	73.5
Effort Required to Lift Rated Load (N)			45	55	100	75	120
Min. Radius of Curve			0.9	1	1.2	1.3	1.4
Dimensions (mm)	A	standard	292	300	314	350	359
		extra long	377	385	395	409	414
	B		225	252	300	360	392
	C		173	188	226	289	313
	E		33	31	32	46	47
	F		≈3
	K		25	30	40	48	60
	L		30	35	47	58	70
Adjustable Beam Width (mm)	M	standard	55-220	58-220	66-220	74-220	90-220
		extra long	160-305	160-305	160-305	160-305	160-305
