Electric Trolley Features
1. Capacity&co
lon; 1T ~ 5T, usually used with chain hoist
2. Power supply&co
lon; 1-3 phase, 50/60Hz, 220/380/440V
3. Co
ntrol voltage&co
lon; 24V/36V/48V
4. Quickly moves loads along I-Beam with the push of a button,
5. Adjustable trolleys fit various size I-beams and wide flange beams
6. Powered trolleys feature a solenoid-operated traveling brake.
7. Durable power coat finish
8. Can be mounted using lug-mount or hook pin.
9. Trolleycan operate on curve I-beam with a minimum radius of 43-5/16"
Electric trolley is also called electric mo
norail car, its using function is similar to the hand trolley, but electric trolley saves more labor and more convenient. Electric trolley is motor as the power, four-wheel walking in the range of I-Beam. It can combine electric hoist and other hoisting tools to form one electric transportation driving, and this driving can be widely used in factories, mine, warehouses for installation, dispatching goods, equipment maintenance.
Electric trolley mainly is used in U Power, Ship, Automobile Manufacture, Construction, Highway, Bridges, me
tallurgy, Mining, Slope Tunnel, infrastructural project of mechanical equipment
* Capacity from 0.5t to 5t...
*Safe, reliable with interlock device.
*Gear hardness&co
lon; HRC32-36 for long life...
*Both single phase and three phase are available...
*One year guarantee...
| model | ETA-010 | ETA-020 | ETA-030 | ETA-050 |
| capacity ton | 1 | 2 | 3 | 5 |
| traveling speed m/min | 20.0/6.7 | 20.0/6.7 | 18.0/6.0 | 18.0/6.0 |
| motor power W | 200/66.7 | 300/100 | 400/133 | 400/133 |
| I-beam | 74-124mm | 74-124mm | 102-152mm | 102-152mm |
