We can offer4x2, 6x4, 8x4, Dongfeng, Sinotruck, FOTON, SHACAN, FAW, CAMC, ISUZU, JMC, etc trucks.
More photos for your reference:
2. Company introduce
HUBEI VELDLION MACHINERY CO., Ltd is an authorized dump truck manufacturer.We arespecialized inthe production of a variety of special-purpose vehicles.
Creatingvalueforourcustomersisourcompany'sconcept.Welcometoenquiryfromus,Let's our sales team make you more great in this field.
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Our Service:
(1) Over 400 workers include our sales and engineers will offer you the best design, price and quality;
(2) Pefect after-sales service, offer long days quality guarantee.
(3) within 7-24 hours feedback.
3. Contact us
Atten: Ms Julia He
Mobile: 0086-15927026165
www.veldlion.com
4. Parameters datasheet
| SINOTRUK HOWO 6X4 MIXER TRUCK LHD / RHD | ||
| Model | ZZ5257GJBN3847 | Driving type: 6X4 |
| Cabin | HW70 standard cab | |
| Engine | Horse power: | 266HP(196KW) / 290HP(213KW) / 336HP(247KW) / 371HP(273KW ) |
| Displacement: | 9.726 (L) liter | |
| Max torque: | 1100Nm / 1160Nm / 1350Nm / 1500Nm at 1100-1600 rpm | |
| Cylinder diameter / stoke: | 126mm/130mm | |
| WD615.62 / WD615.87 / WD615.69 / WD615.47 diesel engine, EURO 2 emission standard. 6 cylinder in-line with water cooling, turbo-charging & inter-cooling. 4 stroke direct injection diesel engine. Compssion ratio: 17:1. Full load fuel consumption: 193g/kwh; Rated revolution: 2200RPM. Engine net weight: 850KG. | ||
| Gear box | Model: | HW13710 / HW19710 |
| Speed: | 10drive, 2reverse. Max torque:1390NM / 1900NM | |
| HW13710 SINOTRUK 10 speed manual type transmission, the first shift gear ratio: 14.08, small ratio grade difference and big first shift ratio produce an excellent performance on start up Gear ratio:1=14.08, 2=10.47, 3=7.82, 4=5.82, 5=4.35, 6=3.24, 7=2.41, 8=1.80, 9=1.34, 10=1, R1=12.67, R2=2.91 HW19710 SINOTRUK10 speed manual type transmission, the first shift gear ratio: 14.28, small ratio grade difference and big first shift ratio produce an excellent performance on start up. Gear ratio:1=14.28, 2=10.62, 3=7.87, 4=5.88, 5=4.38, 6=3.27, 7=2.43, 8=1.80, 9=1.34, 10=1, R1=13.91, R2=3.18 | ||
| Front axle | 1 X HF9, 9 ton axle load, rigid stub axle with double T- cross section and dish / drum brake. | |
| Rear axle | 2 X HC16 / AC16, HC16 heavy casting hub reduction drive axle with super loading ability, excellent performance on start-up with heavy load and slope climbing. AC16 heavy casting hub reduction drive axle, with super loading ability, excellent performance on start-up with heavy load and slope climbing. | |
| Steering | ZF8098 power steering, hydraulic steering with power assistance. | |
| Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance. | |
| Brake | Service brake: Dual circuit compssed air brake. | |
| Parking brake: Spring energy, storage air-break brake. | ||
| Engine brake: Engine exhausted gas brake. | ||
| Electric Equipment | Operating voltage: | 24V negative grounded |
| Battery voltage: | 12V/165Ah,cigar lighter | |
| Tire & Rim | 11.00-20; 12.00-20; 11.00R20; 12.00R20; 295/80R22.5; 315/80R22.5 | |
| Overall Dimension (mm) | 8,715 / 9,040 X 2,496 X 3850 (L X W X H) | |
| Mixer Ball Drum | Capacity 9 / 10 m ³ ; Material: 16Mn, 5mm high-quality wear-resisting manganese alloy steel. | |
| Total Mass (Kg) | 25,000 | |
| Curb Weight (kg) | 13,100 / 13,220 | |
| Maximum Speed (km/h) | 90 / 102 | |
| Color | White, red, yellow, green, blue. | |
