Professio
nal Supplier JIS Dry Charged Battery Truck Power Battery
Quanlity Warranty&co
lon;
Electric Car Seal Lead Acid Battery
The quality guarantee is 12 mo
nths from our manufacture date or B/L date. We will replac
e any defective batteries by new ones.
Certification
ISO9001&co
lon;2000, CE, SASO,SONCAP,etc
Strict Production Procedures Co
ntrol and Respo
nsible staff,
5 Tips To Maintenance Your Car Battery
Your car battery is the heart of your car and if it's not beating with power, your car will o
nly sit still. So take care of your battery and it will keep your car running for along time. There are some fairly simple tips for taking care of your car battery.
Test Your Battery
· Regularly test your battery, particularly before along trip and after it's been recharged. You don't want the battery to fail to start your car when you are far from home.
Park Your Car in aGarage
· An insulated garage helps keep your battery warm in the winter. This means it will be easier for your battery to start your car. If you don't have an insulted garage, then insulate the battery itself with ablanket.
Keep the Battery Clean
· When you test your battery, you might also want to clean it. This means removing the clamps and cleaning off the dirt and grease from the clamps and terminals. You want aclean co
nnection so as not to weaken the charge. Clean the battery case itself with baking soda dissolved in warm water. Dirt can co
nduct electricity and discharge electricity.
Check the Fluid Levels
· When you clean your battery, check the fluid level as well. If it is low, add distilled water to top it off. Keeping the fluid levels full, will help extend the life of the battery. If you don't see any fluid, you may want to replace the battery. The lack of fluid is an indicator that the battery is near the end of its life.
Secure the Battery
· Secure the battery in the mounting bracket. Aloose battery can slide around and become damaged. It might also cause ashort circuit in some cases.
PLEASE Co
nTACT US&co
lon;ELENA HUANG
PHOENIX HEAVY INDUSTRIAL (CHINA) CO.,LTD
Website&co
lon; http&co
lon;//phoenix-china.en.made-in-china.com
Mobile//&co
lon; (0086)15621126030
|
Type (JIS) |
|
|
|
|
|
|
|
|
| NO |
| Voltage | Nominal | CCA (A) | Terminal |
| Plates | Weight |
|
|
| Dimensions(mm) | (V) | Capacity | -18oC | Layout | Terminal | PCS/cell | (KG) |
| New | Old | L xW xH xT.H |
| C20 (Ah) |
|
| Type |
|
|
| P001 | 26A19 | N26 | 187*127*162*184 | 12 | 26 | 180 | 1 | F | Q8-8 | 4.9 |
| P002 | 26A19L | N26L | 187*127*162*184 | 12 | 26 | 180 | 0 | F | Q8-8 | 4.9 |
| P003 | 32B20R | N32 | 195x130x165×195 | 12 | 32 | 210 | 1 | E | Q8-9 | 6.5 |
| P004 | 32B20L | N32L | 195x130x165×195 | 12 | 32 | 210 | 0 | E | Q8-9 | 6.5 |
| P005 | 36B20R | NS40 | 200x130x200×220 | 12 | 36 | 274 | 1 | B | Q9-9 | 7.2 |
| P006 | 36B20L | NS40L | 200x130x200×220 | 12 | 36 | 274 | 0 | B | Q9-9 | 7.2 |
| P007 | 32C24R | N40 | 240x130x200×220 | 12 | 40 | 238 | 1 | A | Q9-10 | 8.1 |
| P008 | 32C24L | N40L | 240x130x200×220 | 12 | 40 | 238 | 0 | A | Q9-10 | 8.1 |
| P009 | 32C24RS | N40S | 240x130x200×220 | 12 | 40 | 238 | 1 | B | Q9-10 | 8.1 |
| P010 | 32C24LS | N40LS | 240x130x200×220 | 12 | 40 | 238 | 0 | B | Q9-10 | 8.1 |
| P011 | 46B24R | NS60 | 240x130x200×220 | 12 | 45 | 325 | 1 | A | Q9-11 | 9 |
| P012 | 46B24L | NS60L | 240x130x200×220 | 12 | 45 | 325 | 0 | A | Q9-11 | 9 |
| P013 | 46B24RS | NS60S | 240x130x200×220 | 12 | 45 | 325 | 1 | B | Q9-11 | 9 |
| P014 | 46B24LS | NS60LS | 240x130x200×220 | 12 | 45 | 325 | 0 | B | Q9-11 | 9 |
| P015 | 48D26R | N50 | 260x170x200×220 | 12 | 50 | 330 | 1 | A | Q12-9 | 9.3 |
| P016 | 48D26L | N50L | 260x170x200×220 | 12 | 50 | 330 | 0 | A | Q12-9 | 9.3 |
| P017 | 55D26R | N50Z | 260x170x200×220 | 12 | 55 | 390 | 1 | A | Q12-10 | 9.9 |
| P018 | 55D26L | N50ZL | 260x170x200×220 | 12 | 55 | 390 | 0 | A | Q12-10 | 9.9 |
| P019 | 65D26R | N60 | 260x170x200×220 | 12 | 60 | 390 | 1 | A | Q12-11 | 10.8 |
| P020 | 65D26L | N60L | 260x170x200×220 | 12 | 60 | 390 | 0 | A | Q12-11 | 10.8 |
| P021 | 75D26R | NS70 | 260x170x200×220 | 12 | 65 | 413 | 1 | A | Q12-12 | 11.2 |
| P022 | 75D26L | NS70L | 260x170x200×220 | 12 | 65 | 413 | 0 | A | Q12-12 | 11.2 |
| P023 | 80D26R | NX110-5 | 260x170x200×220 | 12 | 70 | 413 | 1 | A | Q12-13 | 11.6 |
| P024 | 80D26L | NX110-5L | 260x170x200×220 | 12 | 70 | 413 | 0 | A | Q12-13 | 11.6 |
| P025 | 65D31R | N70 | 310x170x200×220 | 12 | 70 | 430 | 1 | A | Q12-11 | 11.8 |
| P026 | 65D31L | N70L | 310x170x200×220 | 12 | 70 | 430 | 0 | A | Q12-11 | 11.8 |
| P027 | 75D31R | N70Z | 310x170x200x220 | 12 | 75 | 450 | 1 | A | Q12-13 | 12.4 |
| P028 | 75D31L | N70ZL | 310x170x200×220 | 12 | 75 | 450 | 0 | A | Q12-13 | 12.4 |
| P029 | 95D31R | N80 | 310x170x200×220 | 12 | 80 | 480 | 1 | A | Q12-14 | 13.6 |
| P030 | 95D31L | N80L | 310x170x200×220 | 12 | 80 | 480 | 0 | A | Q12-14 | 13.6 |
| P031 |
| N90 | 355x175x190×215 | 12 | 90 | 500 | 1 | A | Q12-16 | 15.2 |
| P032 |
| N90L | 355x175x190×215 | 12 | 90 | 500 | 0 | A | Q12-16 | 15.2 |
| P033 | 95E41R | N100 | 410x175x 205x 225 | 12 | 100 | 512 | 1 | A | Q12-17 | 15.7 |
| P034 | 95E41L | N100L | 410x175x 205x 225 | 12 | 100 | 512 | 0 | A | Q12-17 | 15.7 |
| P035 |
| N100Z | 410x175x 205x 225 | 12 | 105 | 577 | 1 | A | Q12-19 | 16.4 |
| P036 |
| N110 | 430x170x 210x 230 | 12 | 110 | 600 | 1 | A | Q12-19 | 16.4 |
| P037 | 115F51 | N120 | 505x180x 210x 235 | 12 | 120 | 638 | 3 | A | Q12-21 | 20.4 |
| P038 | 145F51 | N135 | 505x180x 210x 235 | 12 | 135 | 699 | 3 | A/E | Q12-23 | 21 |
| P039 | 154G51 | N150 | 505x220x 210x 235 | 12 | 150 | 754 | 3 | A/E | Q12-24 | 23.8 |
| P040 | 165G51 | N165 | 505x220x 210x 235 | 12 | 165 | 820 | 3 | A/E | Q12-25 | 24.5 |
| P041 | 195G51 | N180 | 505x265x 210x 235 | 12 | 180 | 885 | 3 | A/E | Q12-27 | 27 |
| P042 | 190H52 | N200 | 505x265x 210x 235 | 12 | 200 | 924 | 3 | A/E | Q12-29 | 29 |
| P043 | 200H52 | N220 | 505x265x 210x 235 | 12 | 220 | 924 | 3 | A/E | Q12-31 | 29.7 |
|
| US-6TN/100 | 272*265*201*225 | 12 | 100 | 550 | 2 | A | 21 | 17.2 |
|
| US-6TN/120 | 272*265*201*225 | 12 | 120 | 550 | 2 | A | 25 | 19 |
