X4+Y4 Heavy Duty Machine Trolley

Cargo Trolley X+Y Series

1. Capacity of cargo trolleys: 8-36T
2. Rollers of cargo trolleys: 8pcs/12pcs/16pcs
3. Color: Yellow, red orange & etc

8ton to 64ton Hand Cargo Transportation Trolley X+Y Series

- XY series trolley is combined by X series trolley and Y series trolley.
- X series trolley has the advantage of automatic adjustment of balance. It has stable working on rugged site.
- Y series trolley has the advantage of adjustable range, it can be adjusted according to the size of cargos.
- The rollers of these two series are made of special quality material. They have the advantage of anti-abrasion and anti-pssure. The working place won't be damaged easily.

Item No.	Model		Capacity Per set (t)	Touching Face Size(mm)	Handle Length Adjustable Scope(mm)	Shape Size(mm)	Height (mm)	Capacity(single) (T)	A	B	C	D	E
ZHMT-1	X4+Y4	X4	8	φ150	800	230x230	110	4	1000	223	230	130	170
ZHMT-2		Y4		130x130	300-1000	170x140	110	4
ZHMT-3	X8+Y8	X8	16	φ160	1100	560x420	110	8	1130	556	500	200	200
ZHMT-4		Y8		200x160	400-1300	220x200	110	8
ZHMT-5	X12+Y12	X12	24	φ180	1100	750x450	110	12	1130	730	550	256	200
ZHMT-6		Y12		220x180	400-1400	256x200	110	12
ZHMT-7	X18+Y18	X18	36	φ200	1500	750x500	110	18	1430	755	630	256	300
ZHMT-8		Y18		280x180	400-1500	300x250	110	18
