Detailed Description
Hot Sale 6x4 270HP Water Truck with Do
ngfeng Chassis and Cummins Engine
Chassis&co
lon; Do
ngfeng Chassis
Engine&co
lon; Do
ngfeng Cummins engine
Rated Power&co
lon; 198kw/180kw
Drive Type&co
lon; 6x4
Payload&co
lon; 11940kg
Tank Capacity&co
lon; 20000L (20cbm)
Dimensions&co
lon; 9980×2500×3105mm
| Model | QYZ5251GSS4 |
| Chassis Model | DFL1250A11(Euro IV) |
| Drive Type | 6X4 |
| Engine Model | ISDe270 40/ ISDe245 40 |
| Rated Power | 198/180kw |
| Transmission Model | 9JS119 |
| Tank dimensions | 6600×2400×1570 mm |
| Tank Capacity | 20000L |
Main Dimensions
And Weight | Overall Dimensions (LxWxH) | 9980×2500×3105 mm |
| Wheel base | 4350+1300,4350+1350 mm |
| Wheel Tread(Front/Rear) | 1986,2040/1860,1860 mm |
| Approach/Departure Angle | 20/26,20/27(º) |
| Payload | 11940 kg |
| Kerb Weight | 12930 kg |
| GVW | 25000 kg |
Performance | Max. Speed | 80,90 km/h |
| Climbing Degree | 30.1% |
| Fuel consumption per 100km | 28L/100km |
| Braking Length | 8.8 m when initial speed 30km/h |
| Operating Speed | 5~15 km/h |
| Operating gearbox grade | I or II grade |
Dedicated Device Performances | Water pump type | Self-suction centrifugal pump |
| Head of delivery | 110 m |
| Flow | 833 L/min |
| Water absorption depth | ≥4 m |
| Diversion Time | 25 s |
| Watering Quantity | ≥0.25 L/m2 |
| Watering Width | ≥14 m |
| Watering Pressure | 250kPa |
| Watering Time/ tank | 15~25 min |
Product Image
