| Dimenssion | Length(mm) | 10505 | Engine Data | Engine Model | EQB180 (DF Commins engine) |
| Width(mm) | 2500 | Engine Type | In line, 6 cylinder, 4stroke |
| Height(mm) | 3040 |
| Tread(mm) | 5000 | Displacement(L) | 6.234 |
| Wheel base F/R(mm) | 2020/1800 | Max. Powe(KW/rpm) | 132/2600 |
| Overhang F/R(mm) | 2275/3230 | Max. Torque(N.m/rpm) | 700/1400-1600 |
| Approach/Departure (°) | 8/8 | Fuel Type | Diesel |
| Performance | Chassis Manufacture | Hengtong |
| Max. Speed(km/h) | ≥75 |
| Curb Weight(Kg) | 7400 | Max. Grade Ablitiy(%) | ≥20 |
| Engine Position | front | Min. Turning Diameter(m) | ≤24 |
| Brake distance(m) (V=30km/h) | ≤10 | Fuel Tank Capacity(L) | 150 |
| Axle F/R(kg) | 5000/9000 | Max. Total Weight(kg) | 13000 |
|
|
|
| Item | Standard Configiration |
|
| Chassis | Clutch | Single dry plate spring clutch, Friction disc outer diameter 380 |
| Transmission | FAST mechanical Transmission with synchronizer, 5 forward speed 1 reverse speed |
|
| Rear Axle | 9T Axle,Automatic clearance adjusting arm |
|
| Front Axle | 5T Axle,Automatic clearance adjusting arm |
|
| frame | parallel structure; vertical frame: front end as rectangle rear end as trough model section |
|
| Suspension System | multi-pieces leaf spring(F:10/R:12), hydraulic shock absorber |
|
| Steering System | Integral power steering gear |
|
| Brake System | Dual-circuit pneumatic brake ,F/R drum brake ,Energy storage spring brake, ABS |
|
| Tire | 9.00-20-16 |
|
| Electric System | 24V\mongline , cathode ground connection |
|
| Starter | 24v,Electromagnetism Control type |
|
| Battery/Generator | 6-Q-195, 2 pieces/ 28v, 70A |
|
| Other |
|
|
| Body | Body Structure | Semi monoque, Cold-bend type steel framework, Pre-stressed pull skin, fiber glass for F/R surround |
|
| Interior Trimming | ABS absorb plastic interior fitting, PVC agglutination roof and side panel, Polyester frothing roof-side board, absorb plastic front lamp box, Rear lamp box of fiber glass ,absorb plastic door pump box ,Integral Polyester shaped instrument console, rolling curtain for sun visor; curtain for side window |
|
| Door& Door Pump | Front single, mid double Inwards swing Aluminum alloy door, electrical pneumatic door pump |
|
| Window | Front /rear cemented windscreen, top fixing and bottom pull-push type side window, 3 standard roof windows |
|
| Floor | 3 stage-step bus, Bamboo board with Standard floor, Press-punched aluminum floor for horizontal, vertical surface of step |
|
| Seat | 2+2 arrangement,34 plastic seat,one adjustable driver seat |
|
| A/C System | optional (+3500USD) |
|
| Handrail & Ring | Colorful spray handrail, ring |
|
| Audio & Visual | Mp3 vehicle player |
|
| Rear View System | Newman rear view mirror KW28 |
|
| Lamp | Combination headlamp, split type tail-light, 4 LED independent inner roof lights |
|
| Wiper | Asynchronism panorama wiper ( with water spray ) |
|
| Servcie Facility | Electron clock, Aluminum frame tool box,two 2KG Extinguishers for Vehicle Interior, F/R lighting guidepost, plastic garbage can, Roof fan for driver, electric fan. |
|
| Other | Polyester paint, atomic ash |
|
