Dongfeng Styre Double Bridge Fire Fighting Truck (3000L water tank)

Dongfeng Styre double bridge fire fighting truck(3000L water tank)

about us:

EvangelIndustrial(Shanghai)Co.,Ltd.
was founded inSouth Africain 2008, Dongfeng Group, specializes in vehicles and machinery export business critical enterprise.Our main business covers Dongfeng commercial vehicle, passenger car products, automobile equipment and auto parts export.Our products are exported to Southeast Asia, Middle East, South America, Eastern Europe and many other countries.

shortest delivery time
more competitive price
reliable and high efficient performance
good after-sales service

We export commercial vehicles cover all series of Dongfeng Brand.

Dump Truck Series
Cargo Truck Series
Tractor Series
Special Purpose Vehicles
Military Vehicle Series
Passenger Vehicles Series
Specification ofDongfeng Styre double bridge fire fighting truck(3000L water tank):

Type	Water truck
Material	Manganese steel, Q235etc.
Axle number	3 Axle
Leaf spring	-10/10/10,-12/12/12
Tire model	11.00R20 12R22.5 tire
Axles brand	FUWA (BPW optional) etc.
Suspension	Independent stamping steel rigid suspension (or air suspension)
Function	Transportwater
Tractor	50 or 90# tractor
Supporting device	linkage leg
Brake chamber	ABS

Model	Donfeng foam fire fighting truck		Chassic model	EQ1070TJ9AD3
Weight parameter	Rated payload	2000	Outer dimension	6850×2285×2930
	Curb weight	5000	Van size	/
	Max G.Weight	7450	Wheel base	3800
Engine parameter	Model	CY4102-E3C	Type	4 cylinder Turbocharged and Intercooled Diesel Engine
	Power/displacement(kw/ml)	91/3900	manufacture	Dongfeng caochai
Performance parameter	Max speed(km/h)	90	Wheel base	Front axle	1831,1750
	Max gradeablity	23		Rear axle	1640,1586
	fuel consumption/100KM	11	overhang	Front overhang	1180
	Min turning diameter	6.1		Rear overhang	1865
	Min ground clearance	180	Driving angle	Approach angle	20
				Depature angle	11
Special purpose parameter	Tanker capacity(L)	Tanker volume:3000L,foam volume:1000L
	Fire monitor	Model:PS30,range:>=45m
	Fire pump(Atmospheric pssure pump)	Model	BS30	Water suction
		Rated flow	30L/s	Suction time
		Rated pssure	1.0MPa	Driven mode
