A.Widelyusedindifferentareas,mainlyusedinlong-haulfreighttransport.
B.Lightertareweight,strongeranti-knockability,meetdifferentpavement bearing capacity.
C.Reasonablestructure,strongrigidityandstrength,canbeusedtoimpactthebearingthestrike.
DIMENSIONS | ||||||||||||
Tare weight | 7000kg | Payload | 30000 kg | |||||||||
Overall length | 12500mm | Overall width | 2500mm | Overall height | 1500mm | |||||||
SPECIFICATION | ||||||||||||
Chassis | Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac processes.Top flange 12mm,width140mm;Middle Flange 6mm;bottom flange14mm,height :500mm | |||||||||||
Axle | Number | 3 | Brand | HUAYU | Capacity | 13T | ||||||
Suspension | Mechanical suspension american type | |||||||||||
Leaf spring | Leaf spring 8x90x16mm 8 pcs | |||||||||||
Floor | 3mm .checkered plate | |||||||||||
Tire | 12R22.5 double star 12pcs | |||||||||||
Wheel rim | 9.0 12 pcs | |||||||||||
Kingpin | 2'' bolt-in king pin | |||||||||||
Landing gear | Fuwa brand two-speed,manual operating ,heavy duty landing gear 28T | |||||||||||
Twist lock | 12 no.of ISO twist lock for 1x20ft,2x20ft,1x40ft container | |||||||||||
Vehicular applications | Container (20ft.40ft..) transport | |||||||||||
Drawing | Including | |||||||||||
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks .24V | |||||||||||
Paiting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint | |||||||||||
Accessories | One standard tool box | |||||||||||
