It is a mature model of SINOTRUK with the reliable and stable structure design, high bearing capacity, excellent engine force and highly stable performance, with its fame forged in co
nstruction and mining industries with adverse operating environments, available for the short-range earthwork transportation tasks for mines and co
nstruction projects.
| SINOTRUK GOLDEN PRINCE 6X4 DUMP TRUCK |
| MAIN SPECIFICATION |
| Description | SINOTRUK GOLDEN PRINCE 6X4 DUMP TRUCK |
| Model | ZZ3251N3841D1 |
| Engine Power | 340Hp |
| Loading Capacity | 12690Kgs |
| Place of Origin | China |
| DETAIL SPECIFICATION |
| Cabin | Type | L2000, media cabin, one berth, with air-condition |
| Model | L2000 |
| Model | D10.34-40 |
| Engine | Horse Power (Hp/rpm) | 340/1900 |
| Type | Euro IV |
| Clutch | Φ430 Diaphragm spring clutch, hydraulic operating with air assistance |
| Transmission | HW13710C |
| Driving Axle | HC16, Pressed axle housing, central reduction with hub reduction and with differential locks between wheels and axles(Ratio: 4.8, 5.73) |
| Steering System | A01 |
| Electrics | Single wire, 24 V, negative grounded; Alternator: 1540W; Start Motor:7.5kW;Battery:2*12V/165Ah |
| Tire | 12.00R20; Option: 11.00R20 |
| Fuel Tank Capacity (L) | 300 |
| Front Axle Loading Capacity(kg) | 7,000 |
| Rear Axle Loading Capacity(kg) | 16000*2 |
| Vehicle Weight (kg) | 12,310 |
| Gross Vehicle Weight (kg) | 25,000 |
| Rated Loading Capacity(kg) | 12,690 |
| Overall Dimension(L*W*H)(mm) | 8260×2490×3450 |
| Wheelbase(mm) | 3750+1350 |
| Front/Rear Overhang( mm) | 1320/1840 |
| Wheel Track(Front/Rear)(mm) | 1986/1830 |
| Approach/Departure Angle(°) | 20.5/25 |
| Max. Speed (km/h) | 75 |
| Recommended Body Dimension(L*W* H mm) | 5800×2300×1100 |
| Body Capacity(m3) | 14.67 |
