PRODUCTS ADVANTAGE
*OriginalPrice:FOB,CNF/CFR,CIF
*Certificates:CCC,ISO,BV,GJB,CQC
*promptlyDelivery:15-30days
*ExcellentAfter-saleService and Customization Service.
| Vehicle Model | ZZ3167M3811 | |||
| Cabin | HW70 cab. Original luxury Volvo cab with an A/C,No berth, four point full-floating damper, hydraulically damped adjustable drivers seat & rigid adjustable co-drivers seat, heating & ventilation system, etc, Photo for your reference. | |||
| Vehicle Main Dimensions | L×W×H(mm) | 6980×2496×3150 | ||
| Wheel base(mm) | 3800 | |||
| Wheel Track(front/rear)(mm) | 2022/1830 | |||
| Suspended before / after hanging (mm) | 1500/1680 | |||
| Approach/Departure angle(°) | 19/27 | |||
| Minimum ground clearance(mm) | 298 | |||
| Weight in KGS | Tare Weight(kg) | 7950 | ||
| Loading Capacity(kg) | 16000 | |||
| Front axles loading capacity(kg) | 6000 | |||
| Rear axles loading capacity(kg) | 10000 | |||
| Max.Drinving Speed (km/h) | 75 | |||
| Engine | Brand | SINOTRUK | ||
| Model | WD615.87 | |||
| Type | 6-cylinder in-line with water cooling; 4-stroke direct injection; turbo-charging and inter-cooling | |||
| Horse Power(HP) | 290 HP | |||
| Fuel consumption ratio g/(KWh) | 193 | |||
| Emission Standard | Euro II | |||
| Combustion type | Diesel | |||
| Axle | Two axle. | |||
| Front axle | HF9 Drum axle | |||
| Rear Axle | HC16 design overall cast steel axle.Ratio:5.73 | |||
| Gearbox | HW15710. 10 block transmission,Ten forward& Two reverse; | |||
| Clutch | Single-plate dry coil-spring clutch, diameter 420mm, hydraulically operating with air assistance | |||
| Steering Gear | ZF8098,original made in German. Power steering,hydraulic steering with power assistance; | |||
| Fuel Tank(L) | 300L | |||
| Tire | Seven units of 12.00-20 tires.Include one set of spare wheel. | |||
| Brakes | Service brake: dual circuit compssed air brake Parking brake: spring energy, compssed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | |||
| Elective system | ||||
| Operating voltage | 24V, | |||
| Alternator | 1500KW, | |||
| Batteries | 24V/180Ah | |||
| Colour | red,green,white,grey,blue,yellow | |||
| Dump Body | ||||
| Thickness | Side | 6mm in high tensile strength steel Q345B | ||
| Front | 6mm in high tensile strength steel Q345B | |||
| Bottom | 8mm in high tensile strength steel Q345B | |||
| Dump Body Size | L×W×H | 4600mm×2300mm×1500mm | ||
| Tipping Hydraulics | Tipping Type | Middle tipping type | ||
| Tipping System | One set of strengthen F type hydraulics cylinder | |||
