40T 3 axles Lowbed Semi TrailerModel: WL9400TJZP

DimensionsOverall length 12,232mm
Overall height 1,550mm
Overall width 2,500mm
Dimensions mentioned here are approximations.
Capacity
Tare weight: 8,000kgs
payload 40,000kgs
G.V.W.R 48,000kgs
frame:Heavy duty two main fabricated "I" Beam construction (material Q345B/ST52-3)and Londitudnal wise reinforced with Rolled channels, and cross wise bended tapered brackets(material Q235), the deck will covered with 3 mm thickness checked plate, the frame will be reinforced in strength and high tensile.

ISO Standards Twist Locks 12 Units for delivery 1*40', 2*20' 1*20'ISO Standard container
Running gearFUWA high quality Trailer Axle 13Ton three Units (ISO bolts);
Tyres 11.00R-22.5 12Pcs, Brand Chinese Famous;
Wheel Rim 8.0-22.5 12 Pcs; Brand Chinese Famous.

Kingpin 3.5", .

FUWA landing leg;
Electric installationComplete 24V system in explosion proof installation, 7-Pin socket, lamps in accordance with the Standards of China;
AccessoriesSpare tyre carrier winch type 2 Nos.
Tool box 1 Nos;
mudguards;
Steel side protection;
Other terms in accordance with the Standards of CIMC Ruijiang.
PaintingBefore the painting surfaces and accessories are made smooth and then cleaned with a mixture of chemicals;
Steel blasting completely;
Znic-rich Primer Painting + Surface Painting;
Painting in colors in according to customer's wish.
