Sinotruk HOWO Dump Truck Tipper Dumper Truck

2015 New 6*4 Dump Truck for Sale
production describtion

Cabin	Model: ZZ3257N3047N2
	A7-B cab.Original luxury cab with air-condition.
Vehicle Main Dimensions	L×W×H(mm)			7445x2496x3490
	Wheel base(mm)			2975+1350
	Front track (mm)			2022,2041
	Rear track (mm)			1830/1830
	Approach/Departure angle(°)			20/29
Weight in KGS	Tare Weight			11940kg
	Total Weight			25000kg
	Front axles loading capacity			1×7000 Product DescriptionDescription: 1. Model: STQ3256L8Y9S3, Loading capacity:35-50 tons 2. Famous brands of main assemblies, such as Cummins or Yuchai engine, FAST gearbox with American technology, hub reduction rear axle with Benz technology, Aeolus radius tyre etc. 3. Transportation by ro-ro. It can be loaded into container as well if cabin is disassembled from chassis. 4. Service parts are available at any time 5. More than30 yearsprofessional manufacturing experiences 6.ISO9001: 2008certification 7.Manufacture according to your requirements 8. Small order can be accepted 9. We acceptfactory inspectionat any time

Overall Parameters
Truck model	STQ3256L8Y9S3	Approach angle	25°
Color	Red,Yellow	Departure angle	29°
Overall dimension(L×W×H)	8460mm×2490mm×3450mm	Kerb mass	15500kg
Number of tires	10	Regular loading capacity	30000kg~40000kg
Track width (front/rear)	1940mm/1880mm/1880mm	Max. loading capacity	50000kg
Overhang (front/rear)	1460mm/1800mm	Economical speed	60km
Wheel base	3850mm+1350mm	Max. speed	95km
ENGINE
Brand @ Model	Cummins @ L375 30	Intake way	Turbo-charge, inter-cooling
Rated power & speed	375HP(276kw) & 2200rpm	Max. torque/speed	1480N.m @ 1400rpm
Engine type	in-line,4-stroke,water-cooled	Bore x Stroke	114mm×145mm
Displacement	6 cylinders,8.9L,diesel	Min. fuel consumption	≤193(g/KM.h)
Emission standard	Euro-III	Fuel injection pump	Domestic
GEARBOX
Brand @ Model	FAST@Fuller @ 12JS180T
Type	Manual,12 forward gear,1 reverse gear,rated input tonque 1800N.M,with Power take-off
Gearbox ratio	Forward:15.53,12.08,9.39 ,7.33,5.73 ,4.46 ,3.48 ,2.71 ,2.10 ,1.64,1.28 ,1.00 Reverse:14.86
Clutch	Dry type,disc diameter Φ430mm
SUSPENSION SYSTEM
Front axle	Single 7T front axles
Rear axle	Reinforced double 16T hub reduction rear axles. Default axle Ratio: 5.92
Front suspension	With shock absorber,Number/Thickness of leaf spring: 9/18mm
Rear suspension	With shock absorber,Number/Thickness of leaf spring: 12/25mm
BODYWORK DETAILS
Cargo box	Inner dimension of cargo box(L×W×H):5600mm×2300mm×1500mm,Volume:19CBM Cargo box thickness(floor/wall):10mm/8mm
Dump hydraulic system	Front-installed,Φ180mm,single cylinder,F580 gear pump
Cabin	T360 flat-roof,rear mechanical type suspension,3 seats,with sleeper
Chassis frame	Reinforced,frame breadth 320mm,double-deck sheet(8mm+8mm),frame width 860mm
Tire	12.00-20-18 nylon tire,8.5-20 wheel rim
Fuel tank	430L,aluminium alloy
Exhaust system	Muffler,anti-scald board
Electrical system	24V Voltage,2×12V/165Ah Battery
Brake system	1.Service brake:dump-type air brake,2.Parking brake:spring type air shut-off brake, 3.Assistant brake:engine exhaust brake
EQUIPMENT
Power steering	Front & rear bumper	Spare tire	Windscreen wiper
Inter-axle differential	Oil pan protective cover	Tool	Electrical extinguisher
Inter-Wheel differential	Taillight protective cover	Engine tachometer	Cigar lighter & ashtray
Desert air filter	Air conditioner	Seat belt	AM/FM radio & player
Drier	Warm A/C	Front fog lamp	Horn
Sun visor	Power windows	Crystal headlamp	Reversing light & buzzer

Our Services

1. Competitive price from manufacture
2. Professional design and production experience.
3. High quanlity products supply.
4. Efficient after-sales service.
5.ProfessionalFreeDesign
6. OEMsupport
7. LowMOQ

FAQ

1. Q: Are you a manufacturer or trading company?
A: We are manufacturer.

2. Q: What about your products quality?
A:"Quality is priority." We always attach great importance to quality controlling from the very beginning.

3.Q:What payment do you accept?
A: T/T, L/C;

4.Q:What is the MOQ of your products?
A: 1 set.
