Adjustable Cold-Rolled Selective Pallet Racking for Forklift Drive in

Storage Pallet Racking/Rack is commonly used by all kinds of storage area to provide good storage utility and easy picking styles, Also called as "Heavy Duty Racking", "Beam Racking"ect

. Assembled and interlocked configure of the whole system, easy and fast to assemble
. Pitch by 75mm and 50mm of the upright frame
. Quite duty capacity, the max loading capacity is approximately 5000kgs per layer

Specifications

1) High density storage, low capital cost, no crushing of goods
2) No special handling equipment required

Our Storage Rack Advantages1. Color and size can be adjusted according to your requirements.2. Upright and beam is formed by high-quality cold rolled steel, with an omega shaped section to make sure they are very strong.3. Box beam or step beam used. Beam can be freely adjusted by pitch 50mm or 75mm.4. Connection of the upright and beam is by wedging, equipped with safety pin to make sure of the safety.5. Rich accessories: upright protector, guide rail, frame barrier, row spacer, wire decks, steel shelf, etc.6. Stable structure, large loading capacity, convenient sorting.7. Compatible with most type of handling equipment and building structures.8. First level pallets can be placed on the floor.9. Easy to install and dismantle.Our Advantages
1. High and stable quality.2. Delivery timely.3. Excellent rolling technology and patents4. The whole set of perfect production process. (Cutting, roll forming, welding, galvanized, bending, punching machine, powder coated, assembly etc.)

Feature of Pallet racking
Meterial		High-quality steel from BAO Steel Co. Ltd., the largest steel manufacturer in China.
Surface treatmet:		Powder coating; Normal color(Orange or blue) or according to customer' s requirement.
Size	Height	2-11m (6.56-36.1ft), or according to customer' s requirements.
	Width	1.5-3.3m (4.92-10.82ft), or according to customer' s requirements.
	Length	0.8-1.2m (2.63-3, . 94ft), or according to customer' s requirements.
Thickness		Upright: 1.5-2.5mm; Beam: 1.5-2.0. Refer to below sheet 2 for more details.
Spec. of upright		60x55mm, 70x55mm, 90x70mm, 105X70mm, 120x90mm, etc.
Spec. of beam		80x50mm, 90x50mm, 100x50mm, 110x50mm, 120x50mm, 140x50mm, etc.
Loading capibility (per layer)		700-4000kg (1 543-8 818lb). Refer to below sheet 2 for more details.
Layer nos.		2-7 layers. or customized.
Packing detial:		Experienced export packing (uprights and beams' both end with cardboard, then bundled tightenly with plastic belts, safe for long-distance transportation) also we can follow your requirement.
Delivery detial:		10-15 ton per 1x20ft container, 20-25 ton per 1x40ft container. 15-20 workdays after received the deposits.
