PalletRacks/PalletRacking/WarehouseRack/PalletRackManufacturer
This pallet rack is the most cost effective storage system with the lowest equipment and capital costs. It provides direct access to all pallets for 100% accessibility and good stock rotation.
Features:
(1) Excellent in quality and beautiful in appearance with high quality steel.
(2) Surface: Power coating. Smooth surface, do not rust, be anti-corrosive, non-toxic.
(3) Available with large loading capability: 1000KG-5000KG/Layer,
Large load bearing: 8000KG-12000KG/Bay.
(4) Beam levers are adjustable in 75mm pitch interval.
(5) Different sizes, various specifications and colors are available according to
Customers' different needs.
(6) Popular in South America, Europe, Australia and Asia etc.
(7) OEM orders are welcome.
Our Storage Rack Advantages
1. Color and size can be adjusted according to your requirements.
2. Upright and beam is formed by high-quality cold rolled steel, with an omega shaped section to make sure they are very strong.
3. Box beam or step beam used. Beam can be freely adjusted by pitch 50mm or 75mm.
4. Co
nnection of the upright and beam is by wedging, equipped with safety pin to make sure of the safety.
5. Rich accessories: upright protector, guide rail, f
rame barrier, row spacer, wire decks, steel shelf, etc.
6. Stable structure, large loading capacity, co
nvenient sorting.
7. Compatible with most type of handling equipment and building structures.
8. First level pallets can be placed on the floor.
9. Easy to install and dismantle.
Our Advantages
1. High and stable quality.
2. Delivery timely.
3. Excellent rolling technology and patents
Services:
Our free services include co
nsultations and sample CAD layouts of your proposed rack system. Don't hesitate to co
nsider reviewing the racking systems on site or at our headquarters. Get the racking system you need at the best price guaranteed.
Remark:
We are very professio
nal in producing various pallet racking, lo
ngspan shelving, cantilever racks, rivet shelving, drive in racks, steel mezzanine, carton flow racking and other related storage equipments.
Please don't hesitate to co
ntact us, we are very co
nfident to provide you with satisfying products!
| Feature of Pallet racking |
| Meterial | High-quality steel from BAO Steel Co. Ltd., the largest steel manufacturer in China. |
| Surface treatmet: | Powder coating; Normal color(Orange or blue) or according to customer' s requirement. |
| Size | Height | 2-11m (6.56-36.1ft), or according to customer' s requirements. |
| Width | 1.5-3.3m (4.92-10.82ft), or according to customer' s requirements. |
| Length | 0.8-1.2m (2.63-3.94ft), or according to customer' s requirements. |
| Thickness | Upright: 1.5-2.5mm; Beam: 1.5-2.0. Refer to below sheet 2 for more details. |
| Spec. of upright | 60x55mm, 70x55mm, 90x70mm, 105X70mm, 120x90mm, etc. |
| Spec. of beam | 80x50mm, 90x50mm, 100x50mm, 110x50mm, 120x50mm, 140x50mm, etc. |
Loading capibility
(per layer) | 700-4000kg (1 543-8 818lb). Refer to below sheet 2 for more details. |
| Layer nos. | 2-7 layers. or customized. |
| Packing detial: | Experienced export packing (uprights and beams' both end with cardboard, then bundled tightenly with plastic belts, safe for long-distance transportation) also we can follow your requirement. |
| Delivery detial: | 10-15 ton per 1x20ft container, 20-25 ton per 1x40ft container. 15-20 workdays after received the deposits. |
