| parameter | HBT15-5-22 | HBT20-6-30 | HBT30-8- 45/55/75 | HBT60-13- 75/90 | HBT80C/ D-13/16-90/110 | HBT90-20-180 |
| Conveying capacity (low pssure) m³/h | 15 | 20 | 72 | 83 | 86/69 | 95 |
| Conveying capacity (high pssure) m³/h | 40 | 49 | 51/40 | 20 | ||
| Max pump conveying pssure Mpa | 5 | 6 | 8 | 13 | 13/16 | 11 |
| Hydraulic type | Open type | Open type | Open type | Open type | Open type | Open type |
| Power type | Electric engine | Electric engine | Electric engine | Electric engine | Electric engine | Electric engine |
| Rotary Speed | 1480 | 1480 | 1480 | 1480 | 1480 | 1480 |
| Power | 22 | 30 | 45/55/75 | 75/90 | 90/110 | |
| Distributing valve type | S valve | S valve | S valve | S valve | S valve | S valve |
| Oil cylinder size | 100 | 100 | 100 | 125 | 125/140 | 160 |
| Conveying cylinder size | 200 | 200 | 200 | 200 | 200 | 200 |
| Switch of high and low pssure | NO | NO | NO | YES | YES | YES |
| Hydraulic Oil tank volume (L) | 150 | 200 | 460 | 580 | 580 | 800 |
| Volume of hopper | 0.3 | 0.35 | 0.8 | 0.8 | 0.8 | 0.8 |
| Loading height(mm) | 1100 | 1100 | 1280 | 1380 | 1380 | 1430 |
| Size(m) | 3.9×1.35×1.45 | 4.45×1.6×1.5 | 5.4×1.86×1.9 | 6×2.16×2.3 | 6×2.16×2.3 | 7×2.3×2.6 |
| Weight(kg) | 1950 | 2500 | 5400 | 6000 | 6150 | 7000 |
| Specifications | SHBT90.11.140RS | SHBT90.13.176RS | SHBT90.16.176RS | SHBT90.18.176RS | SHBT100.18.181RS |
| Conveying capacity (low pssure)m³/h | 90 | 96 | 98 | 98 | 98 |
| Conveying capacity (high pssure)m³/h | 61 | 53 | 63 | 55 | 55 |
| Conveying pssure (low pssure)Mpa | 8 | 7.5 | 9.2 | 10 | 10 |
| Conveying pssure (high pssure)Mpa | 11.8 | 13.6 | 15.6 | 18 | 18 |
| Hydraulic system pssure Mpa | 32 | 32 | 32 | 32 | 32 |
| Switch of high and low pssure | auto | auto | auto | auto | auto |
| Fuel tank capacity ml | 190 | 190 | 260 | 260 | 260 |
| Power KW | 140 | 176 | 176 | 176 | 181 |
| Rotary Speed r/min | 2200 | 2200 | 2200 | 2200 | 2200 |
| Hopper Volume m³ | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Hydraulic Oil tank volume L | 600 | 600 | 600 | 600 | 600 |
| Conveying distanceφ125) mHorizontal/Vertical | 860/200 | 860/210 | 960/250 | 960/260 | 960/260 |
| Diameter of Cylinder without bore mm | 125 | 150 | 140 | 150 | 150 |
| Diameter of Cylinder bore mm | 80 | 100 | 90 | 100 | 100 |
| Diameter of Concrete cylinder | 230 | 230 | 200 | 200 | 200 |
| Cylinder push distance mm | 1600 | 1600 | 1600 | 1600 | 1600 |
