| Dimensions: | ||
| Overall size(length × width × height) | 10207mm× 2496mm× 3115mm | |
| Wheel base | 1800+3200+1350mm | |
| Wheel track(Front/Rear) | 2022/2041/1830mm | |
| Ground clearance | 298mm | |
| Weight: | ||
| N. V. W | 15030kg | |
| Payloading capacity | 15970kg | |
| G. V. W | 31000kg | |
| Axle loading capacity(Front/Rear) | 2x7000/2x9000kg | |
| Performance: | ||
| Max. traveling speed | 90km/h | |
| Min. turning diameter | 23m | |
| Grade ability | 48% | |
| Approach angle | 19° | |
| Departure angle | 18° | |
| Fuel consumption | 38L/100km | |
| Engine | ||
| Model | WD615.69 | |
| Type | Direct injection, turbocharged, water cooled | |
| Rated power | 247kW | |
| Transmission: | ||
| Type | Fuller 9, forward 9, reverse 1 | |
| Ratio | 12.11; 8.08; 5.93; 4.42; 3.36; 2.41; 1.76; 1.32; 1.00; 12.66R | |
| Steering: | ||
| Type | ZF8098, hydraulic steering with power assistance | |
| Ratio | 22.2~26.2 | |
| Front axle | ||
| HW07, rigid stub axle with double T-cross section | ||
| Rear axle | ||
| STEYR pssed axle housing, dual reduction with hub reduction | ||
| Ratio | 5.73 | |
| Clutch | ||
| Single-plate dry coil-spring clutch, diameter 420, hydraulically operated with air assistance | ||
| Brakes | ||
| Service brake-Dual circuit compssed air brake | ||
| Parking brake-Spring energy operating on rear wheels | ||
| Auxiliary brake-Engine exhaust brake | ||
| Tyres | ||
| Tyres | 12.00R20 | |
| Mixer Drum | ||
| Effective capacity | 10m 3 | |
| Leaning angle | 12 o | |
| Rotation speed | 0~14rpm | |
| Feeding speed | ≥ 3m 3 /min | |
| Discharging speed | ≥ 2m 3 /min | |
| Landslide degree | 50~210mm | |
| Surplus rate | ≤ 1% | |
| Water tank | 400L | |
