Carriage volume: | 8m³ | ||
Dimension(Lx WxH)(unloaded)(mm) | 9040×2496×3850 | ||
Approaching angle/Departure angle(°) | 19/23 | ||
Overhang(front/rear) (mm) | 1500/1870 | ||
Wheel base (mm) | 3800+1350 | ||
Max speed(km/h) | 75 | ||
Curb weight(kg) | 13220 | ||
Engine (Steyr technology, made in China) | Model | WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection | |
Fuel type | Diesel | ||
Power, max(kw/rpm) | 247/2200 | ||
Emission | EURO II | ||
Fuel tanker capacity (L) | 300 | ||
Transmission | Model | HW15710,10 forward&2 reverse | |
Brake system | Service brake | Dual circuit compssed air brake | |
Parking brake | spring energy, compssed air operating on rear wheels | ||
Steering system | Model | ZF8098 | |
Front axle | HF9 | ||
Rear axle | HC16 | ||
Tyre | 12.00R20 | ||
Electrical system | Battery | 2X12V/165Ah | |
Alternator | 28V-1500kw | ||
Starter | 7.5Kw/24V | ||
Cab | HOWO76 cab(Single bed,A/C),all-steel forward control,55ºhydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | ||
Carriage dimension: | 12m³ | ||
Dimension(Lx WxH)(unloaded)(mm) | 10820×2496×3900 | ||
Approaching angle/Departure angle(°) (°) | 19/23 | ||
Overhang(front/rear) (mm) | 1500/1870 | ||
Wheel base (mm) | 1800+3800+1350 | ||
Max speed(km/h)(km/h) | 75 | ||
Curb weight(kg) | 17320 | ||
Engine (Steyr technology, made in China) | Model | WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection | |
Fuel type | Diesel | ||
Power, max(kw/rpm) | 247/2200 | ||
Emission | EURO II | ||
Fuel tanker capacity (L) | 300 | ||
Transmission | Model | HW15710,10 forward&2 reverse | |
Brake system | Service brake | Dual circuit compssed air brake | |
Parking brake | spring energy, compssed air operating on rear wheels | ||
Steering system | Model | ZF8098 | |
Front axle | HF9 | ||
Rear axle | HC16 | ||
Tyre | 12.00R20 | ||
Electrical system | Battery | 2X12V/165Ah | |
Alternator | 28V-1500kw | ||
Starter | 7.5Kw/24V | ||
Cab | HOWO76 cab(single sleeping bed,A/C),all-steel forward control,55ºhydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | ||
