Model | NXG5251KGJB3A | NXG5250KGJB3 | NXG5250KGJB3B | NXG5251KGJB3B |
Drive type | 6×4 | |||
Parameters | ||||
Max.travel speed(km/h) | 80 | 80 | 80 | 80 |
Max.gradeability(%) | ||||
Max.braking gradient(%) | ||||
Min.turning diameter(m) | ||||
Fuel Tank Capacity(L) | 240 | 240 | 240 | 240 |
Min.ground clearance [full load](mm) | 245 | 245 | 245 | 245 |
Electric system(v) | 24 | 24 | 24 | 24 |
Weight | ||||
Curb weight(kg) | 13650 | 14620 | 13650 | 13650 |
Rated load(kg) | 11150 | 10180 | 11150 | 11150 |
Max.total weight(kg) | 24995 | 24995 | 24995 | 24995 |
Dimension | ||||
Total length(mm) | 9020 | 9720 | 9020 | 9020 |
Total width(mm) | 2500 | 2500 | 2500 | 2500 |
Total height [no-load](mm) | 3900 | 3995 | 3900 | 3900 |
Wheel base(mm) | 3650+1350 | 4000+1350 | 3650+1350 | 3650+1350 |
frame(mm) | 320 | 320 | 320 | 320 |
Leaf spring | 9/13 | 9/13 | 9/13 | 9/13 |
Main Parts | ||||
Cab | Medium top | Medium top | Medium top | Medium top |
Engine | WP10.270N | WP10.336N WD615.95C | ISLe340 30 | WD615.92C YC6M290-32 |
Transmission | 9JS135 | RT-11509c | RT-11509c | 9JS135 |
Front Axle | 7.5 ton | 7.5 ton | 7.5 ton | 7.5 ton |
Rear Axle | Steyr Middle/rear | Steyr Middle/rear | Steyr Middle/rear | Steyr Middle/rear |
Tire | 12.00R2012.00-20 | 12.00R20 12.00-20 | 12.00R20 12.00-20 | 12.00R20 12.00-20 |
Compartment dimension(inner)L×W×H | 9M 3 | 12M 3 | 9M 3 | 9M 3 |
