Concrete Mixer TruckTruck MixerConcrete Mixer

Product Description
HOWO 6X4 Mixer
Engine: CNHTC HOWO brand WD615.69, 336HP
Transmission: HOWO 10speed
Steering: HOWO ZF8098 hydraulic steering with power assistance
Cab: HOWO 76 standard cab, air conditioner, one bunk
Rim/Tyres: 12.00-20 bias tyre
Cubage: 8m3
Fuel tank: 300L tank
Optional tank: 9M3

HOWO 8X4 Mixer
Engine: CNHTC HOWO brand WD615.69, 336HP
Transmission: HOWO 10 speed
Steering: HOWO ZF8098 hydraulic steering with power assistance
Cab: HOWO 76 standard cab, air conditioner, 1 bunk
Rim/Tyres: 12.00-20 bias tyre
Cubage: 10m3
Fuel tank: 300L tank
You can select cubage 9m3, 10 m3, 12 m3

1. Tipper truck: 4X2, 4X4, 6X4, 6X6, 8X4, 10X6
2. Tractor truck: 4X2, 4X4, 6X4, 6X6
3. Cargo truck: 4X2, 4X4, 6X4, 6X6, 8X4
4. Concrete mixer: 6X4, 8X4
5. Water tank truck: 4X2, 6X4, 8X4
6. Oil tank: 4X2, 6X4, 8X4
7. Semi trailer: Container trailer, cargo trailer, low bed trailer
8. Light truck
1) Diesel Flatbed Truck: Loading 0.5 ton, 1 ton, 2 ton, 3 ton, 3.5 ton, 5 ton;
2) Diesel BoxTruck: Loading 0.5 ton, 1 ton, 2 ton, 3 ton, 3.5 ton, 5 ton;
3) Diesel Dump Truck: Loading 2 ton, 3 ton, 5 ton, 7 ton, 10 ton, 12 ton;
4) Petrol Flatbed Truck: Loading 0.5 ton, 2 ton, 3 ton;
5) Petrol Box Truck: Loading 0.5 ton, 2 ton, 3 ton;
6) CNG Flatbed Truck: Loading 0.5 ton, 2 ton, 3 ton;

1. Double Logarithmic Variable Pitch Helical Mixer Blade enables higher charging and discharging speed and equal mixing, eliminates segregation phenomenon, and is suitable for the transportation of both dry and wet materials;
2. New technology T-shape Blade. It is made of hard-wearing alloy steel, and thus protects the mixer blades from abrasion, extends the service life of the agitator drum, and enhances mixing performance;
3. The geometric capacity of the agitator drum is very large and the filling rate is low, thus guaranteeing more mixing space. The small inclined angle and low center of gravity help reduce the possibility of turning over.
4. Closed loop hydraulic system and constant hydraulic oil temperature controller are used. Key hydraulic accessories include: Hydraulic plunger pump, adjuster mechanism with servo, hydraulic motor and reducer are all made by internationally known brands and offer stable and reliable and reliable performances.
5. Pneumatic Water Supple System. The pssure is provided by the air tank on the chassis with pssure protection devices. The Water inlet connector fits for both normal water pipe and fire fitting.
6. Multi-outlet washing design. Cleaning requirements are met by the three fixed pipes for washing the agitator drum, charging hopper and discharging hopper respectively, and another flexible water outlet.
7. Three-point Operation System. One in the cab to allow control of the agitator drum to turn forward and reverse, and to perform the "feed", "discharge", "agitate" and "stop" functions. Two at the rear with one operation handle at each side to perform "charge" "accelerate", "discharge", "agitate" and "stop". Three are interlocking.
8. Colors can be customized.


Product Description
HOWO 6x4 Concrete Mixer Truck In stock with Special Offer
Lead Time: 5 days
Quantity: only 5
Price: USD52000-55000/unit FOB Shanghai port

Engine 371HP
Emission standard Euro II
Gear box Manual operating, HW19710
Front Axle HF9 Disc brake
Rear Axle HC16, speed ratio 4.8
Tyre 12R22.5

Mixer Drum
Volumn 10CBM
Water Supply Patterns Air Pressure
Tilt 11-13
Hydraulic Reducer, Motor, Pump Made in Europe/United State
We also have Other mixer trucks:
4x2 small / mini mixer truck, 6x4 mixer truck, 6x6 mixer truck, 8x4 mixer truck, 3axles mixer semi trailer....

Drive Type	Mixing tankcapacity	Chassis brand
4x2	2cbm to 6cbm	Dongfeng,yuejin,forland,CDW,etc
6x4	8cbm to 12cbm	Dongfeng,FOTON,SINOTRUK,SHACMAN,JAC,Beiben,HINO,etc
8x4	10cbm to 16cbm	Dongfeng,FOTON,SINOTRUK,SHACMAN,JAC,Beiben,HINO,etc
mixer semi trailer

MAIN DEscriptION
Overall Dimensions	9780mm*2496mm*3990mm(L*W*H)
Tare Weight	13950kg	Payload	28000kg
Front Overhang	1500mm	Rear Overhang	2880mm
Wheelbase	4000mm+1400mm	Track (F/R)	2022mm/1830mm
CHASSIS
Chassis Brand	SINOTRUK HOWO
Chassis Model	ZZ1257N4048W, driving type 6x4
Cab	HW76, left hand drive, air-conditioner, one sleeper
Engine	SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L
Transmission	HW19710, No. of speeds: 10 forward 2 reverse
Steering	German ZF8098, turning system pssure 18MPa
Rear Axle	HC16 tandem axle, rated load 2x13ton, ratio 5.73
Wheels and tires	Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel
Brakes	Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compssed air operating on rear wheels; Auxiliary brake: Engine exhaust brake
MIXING SYSTEM
Mixing Volume	10cbm
Water Tank Volume	440L
Hydraulic Pump	Brand: ARK, Italy
Motor	Brand: ARK, Italy
