2. Double screw blades make sure the concrete mix very thoroughly and continuous discharge and not segregation;
3. The mixing drum is made from the special close grain high-hardness steel plate B520JJ which is produced by Shanghai Baosteel and its service life can last 8-10 years;
4. With the minor angle inclination, the gravity of the whole truck is low and stable;
5. Equipped with the large diameter hopper, it can realize the quickly feeding, not plugging and spilling, and it is easy to clean;
6. With the discharge downspouting to pave the way for the quick and clean discharging;
7. The optimized design of mixing drum and no dead angles to ensure the concrete residue ratio is less than 1%;
8. With the pedal, security barrier and anti-skid design to ensure personal safety;
| model | JC3m³-D | JC6m³-D | JC8m³-D | JC8m³ | JC12m³ |
| overall dimension(L*W*H)(mm) | 3983*(1100+943)*2175 | 5180*(1125+1046)*2580 | 6015*(1150+1100)*2632 | 6015*(1150+1100)*2632 | 7300*2372*2750 |
| the dimension of bottom machinery(L*W*H)(mm) | 3200*860*120 | 4430*860*140 | 4900*860*160 | 4900*860*140 | 6100*860*140 |
| nominal mixing capacity of tank | 3m³ | 6m³ | 8m³ | 8m³ | 12m³ |
| geomerical volume of tank | 5.5m³ | 9.6m³ | 13.4m³ | 13.4m³ | 19m³ |
| coefficient of loading ration | 0.545 | 0.625 | 0.545 | 0.545 | 0.63 |
| drum roating speed | 0-14rpm | 0-14rpm | 0-12.5rpm | 0-14rpm | 0-14rpm |
| inclinated angle of mixing tank axial line | 16º±15´ | 15º±15´ | 15º±15´ | 15º±15´ | 11º±15´ |
| inlet height(mm) | 2072 | 2446 | 2552 | 2552 | 2750 |
| inclinated angle of discharge duct | 45º | 45º | 45º | 45º | 45º |
| dumping direction of discharge duct | 180º | 180º | 180º | 180º | 180º |
| legth of discharge duct | 1900(1450+450)mm | 1900(1450+450) mm | 1900(1450+450) mm | 1900(1450+450) mm | 1900(1450+450) mm |
| the concrete slump that is suitable for conveying | 40-210 | 40-210 | 40-210 | 40-210 | 40-210 |
| residual rate | <1% | <1% | <1% | <1% | <1% |
| water tank capacity | 180L | 180L | 180L | 180L | 180L |
