40T Multi-purpose Transport Bogie Powered by Dragged Cable
a
bout our company
Xinxiang Hundred Percent Electrical and Mechanical company is the famous transport bogies manufacturer in China, a
large amount of high-quality transport bogies are designed and finished by the aid of advanced technology.
a
bout our products
(1)Working principle
Powered by the mobile cable, this kind of transport bogie co
nducts AC 380V directly into the electrical co
ntrol system
of the transport bogie to let it start, stop, go forward, backword and so on. The bogie is powered by dragging cable
which is laid on the ground. The cable line is placed between the two rails. The operation system is low voltage 36V
power.
(2)Advantages
1. High using frequency
2. Low cost
3. Easy operation
4. Low maintenance cost
5. The using time is unlimited
6. No strict requirement for the railways
(3)Application
This series' transport bogie can be used in the bad environment, for example, high-temperature and anti-explosion
condition. With its simple structure and low price, this series is more often used to transfer materials for a short
distance from one workshop to another. This series' transport bogie is suitable for the enviro
nment of short running
distance which is no more than 20m, the cart's weight is low. For the co
ndition of short running distance and lowered
speed, the chain can be used to reduce the abrasion of the cable.
(4)Components
Transport bogie f
rame, AC electric motor, gear reducer, bogie wheels, cable, push button pendant, remote controller,
alarm light.
(5)Detailed Product Des
cription
1, Certification: ISO9001
2, Warning light
3, High temperature resisting and anti-explosion
4, Manufacturer
5, Retail
| Model | KPT-40T |
| Rated Load(t) | 40T |
| Table size(mm) | 5000*2500*650 |
| Wheel base(mm) | 3800 |
| Rail Gauge(mm) | 1435 |
| Wheel Diameter(mm) | 500 |
| Wheel Quantity(Pcs) | 4 |
| Ground Clearance(mm) | 50 |
| Running Speed(m/min) | 20 |
| Motor Power(Kw) | 5.5 |
| Max Wheel Load(KN) | 142.8 |
| Reference Weight(t) | 7.2 |
| Recommended Rail Model | P43 |
