Detailed Description
China Top Brand 4.1M 4x2 Do
nGFENG Refrigerated Truck
Engine&co
lon; Yuchai Engine
Rated Power&co
lon; 73Kw/100HP
Drive Type&co
lon; 4×2/LHD
Cabin&co
lon; Flat roof with single row cabin
Rated Payload&co
lon; 1495 kg
Box Dimensions&co
lon; 4100
x1910x1990 mm
| Model | DonGFENG Refrigerated Truck | Chassis Model | DFA1041SJ35D6 |
Weight
(kg) | Rated Payload | 1495 | Dimension (mm) | 5995×2090×2950 |
| Max. Curb Weight | 2870 | Box Dimension (mm) | 4100x1910x1990 |
| Max. Gross Weight | 4495 | Wheel base (mm) | 3300 |
| Engine | Engine Model | CY4102 | Type | 4 cylinder, Euro4 |
| Power/Displacement (kw/ml) | 73/3856 | Brand | Yuchai brand |
| Performance | Max. Speed (km/h) | 95 | Wheel Tread (mm) | Front Axle | 1404 |
| Max. Gradeability (%) | 23 | Rear Axle | 1458 |
| Fuel Consumption per hundred meters (L) | 11 | Overhang (mm) | Front Overhang | 1032 |
| Ability of located at slope when empty tank (%) | 20 | Rear Overhang | 1513 |
| Min. Turning Diameter (m) | 13 | Travel Angle (°) | Approach angle | 19 |
| Spring No.(Front/Rear) | 8/9+5,6/8+4 | Departure angle | 16 |
| Cabin | Flat Roof, single row cabin |
| Tyre | 8.25-16 |
| Features | The refrigerated truck:
The box is made of plastic composite with full-enclosed combined structure, the skin material of inside and outside is glass epoxy, and the intermediate interlayer is Polyurethane foam insulation material. Domestic refrigeration unit, lowest temperature can reach -10ºC,the imported refrigeration unit is optional. |
Product Image
