10000L Do
ngfeng water tank truck (B170-33)
T
He im
ported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy co
nservation co
ntrol can reduce the oil co
nsumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic pheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart pvention system effectively avoids the misoperation, and improve the use security of the machine.
| Chassis Information |
| Chassis Brand | Dongfeng |
| Chassis brand | EQ1110GLJ |
| Drive type | 4×2 |
| Dimension Parameter |
| Overall dimension (L*W*H) (mm) | 7650*2480*3000 |
| Wheel base (mm) | 3950 |
| Wheel No. | 2 |
| Front/ Rear track (mm) | 1900/1800 |
| Weig h t Parameter |
| GVW (kg) | 11495 |
| Payload weight (kg) | 5480 |
| Kerb weight (kg) | 5820 |
| Front / Rear axle (T) | 2.8T / 8T |
| Engine Parameter |
| Model | B170-33 |
| Manufacturer | Dongfeng Cummins |
| Horsepower (hp) | 170 |
| Displacement / power (ml/kw) | 5900/125 |
| Emission Standard | Euro III |
| Transmission |
| Control type | manual |
| Gear Shift | 5forward and 1reverse speeds |
| Tyre |
| Type | 9.00-20 |
| Tyre No. | 6+1 spare tyre |
| Cab |
| Type | flat roof cab, blue color |
| Up-load Special Parameter |
| Tankmaterial | carbon steel |
| Thickness of the tank | 4mm (seal head 5mm) |
| Water pump | Hangzhou Weilong (China famous brand) |
| Equipment | Front dash, rear & side sprinkler, water connon, working platform |
