50 Ton Tri-Axle Extendable Low Bed Semi Truck Trailer

Product Introduction
50 Ton Tri-Axle Extendable Low Bed Semi Truck Trailer

Dimension
Trailer Model		QLG9400TDP
Overall dimension		13000*3200(2800-3200)*1750mm
Platform (mm)		1100mm height , 8000mm effective length .
Effective platform		8000mm length
Main Beam		The height of Main beam is 500mm,The upper/down plate is 20 mm, width is 140mm. the middle plate is 10mm
Side beam		250mm I-beam
Cross beam		16# I-beam
Platform		4mm checkered plate
Max Payload		60-70Tons
frame and running constructon
Axle		FUWA 13T/ 3pieces
tyre		Triangle 8.25R20/ 12 pieces
rim		6.5-20/ 12 pieces
leaf-spring		90mmwidth*10pieces*13mm/6sets
Kingpin		Interchangeable 50# &90#
Landing gear		28T standard made in China
Hydraulic system		1 set to control rear ladder
rear ladder		1 set
suspension		Mechanical suspension
Electrical and braking system
Electrical system		24 volt electrical system. LED lights, 7pin electrical connector. Parking .stop,reverse, number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors
Color		Optional
Braking system		with ABS system made in China
Packing		Nude,Polish with Wax before Shipment
Remark		The above mentioned data is for your reference only. The detailed specification will be subject to our final /confirm/iation.

Lowbed rack is welded by submerged welding machine from 20 mm x150 mm ST52.3 Quality steel bottom and top flat steel and 10 mm ST52.3 hub plate. It has "I" section and also includes 4pcs.
Rack is supported with 160 NPI axle beams that crosses rack.
It has been produced in welding constructions with gas metal arc welding as "I" crossing from high resistant steel considering overloads proper to capacity and intended usage.
Platform size: 8000 -10500 mm varies according to demand. Lowbed can be extendable.
Total Length: Variable
Total Width: 2550 mm -3500 mm varies according to demand.

AXLES:
3 pcs Axles, each one is with 12-14-16 tons capacity according to the trailer drum or disc brakes, hub centric, with 10 wheel nuts, and automatic slack adjuster.

LOADING RAMPS:
Manufactured with air or hydraulic piston from NPU with 160

BRAKE SYSTEM:
The WABCO or Haldex brand ABS or EBS brake system which is designed according to the European Standards is used. It consists of automatic brake ratchets, brake valves and brake bellows of 30.

SUSPENSION SYSTEM:
It consists of automatic height adjusting system, Parabolic Zleaf springs, Suspension bellows, shock absorbers restricting extensive shaft movements and vibrations.
Mechanical leaf spring suspension system.

ELECTRIC SYSTEM:
24 Villumination systems in conformity with the international standards, lamp with 7functions, and electric socket with 7pins are used. There are traffic warning panels on the vehicles.

PARKING LEGS:
Consists of double cycle telescopic legs each of which has acapacity of 24 tons.

KING PIN:
King pin compliant with SEA/DIN norms and manufactured from steel (42 Cr Mo 4) which is highly resistant to being cut, stretched and broken off is of flange type and can be disassembled and assembled back.

TIRES AND WHEEL RIMS:
12+1 tires are used with different dimensions. Dimension that we use are; 235/70 R17.5
245/70 R17.5
295/60 R22.5
12 R22.5
315/80 R22.5

STANDARD ACCESSORIES:

Water Retainer Mat, Spare tyre carrier, Wheel leaning mounting, Fire extinguisher pserving cabinet.

OPTIonAL FEATURES:
Lowbed platform can be pool type
BPW, SAF, Gigant Axle drum or disc axle can be pffered.
Chassis and side walls group manufactured from imported metal sheet (Hardox or Domex).
Aluminum Rims.
Tire mark according to request.
