| Tank Body |
| Shape | One v-shaped silo, double silo, or triple silo design |
| Dimension | 12000mm×2490mm×3990mm ( The exact size depends on the final design. ) |
| Tare Weight (Semi Trailer) | about 7500kg-15000kg |
| Total Volume (m3) | 30m³ -68 m³ |
| Tanker Body Material | 5mm or 6mm/ Q235 carbon steel |
| End Plate | 5mm or 6mm /Q235 carbon steel |
| Diesel Engine | WEICHAI, Tianhe 4100/4102 or other brands |
| Compssor | BOHAI 10m³/12 m³or other brands |
| Manhole Cover | Carbon steel or Aluminum 500mm(Diameter) |
| Discharging Valve | Diameter is 3 or 4 inch (Material: Aluminum) |
| Discharging Pipe | 3 or 4 inch rubber hose, 1pcs, 6m/each |
| Cat Walk | With (Common model or special design) |
| Chassis |
| Main Beams | Welded design, Q345 carbon steel |
| Axle | 2 or 3 axles, 12T/13T/16T, BPW/FUWA/HUAJING brand |
| Landing Gear | JOST (D200T) or CHINA BRAND 28T |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension/Germany or America type /Air Suspension |
| Leaf Spring | 90(W)mm×13(Thickness)mm×10 Layers or 100mm×12mm×12 layers |
| Pneumatic Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (TKL brand); 45L air tank |
| Rim | 9.00-22.5/8.00-20/8.5-20 Chinese Brand |
| Tire | 12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
| ABS | Optional |
| Semi Trailer Surface Coating | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Accessories | One standard tool box |
| Shipping Terms | By bulk cargo, RORO |
