| Semi Trailer Dimension | 11280×2495×3970mm (Outside Dimension)10500×2300×1700mm (Inside Dimension) |
| Tare Weight | about 15600kg |
| Total Volume (m3) | 37 m³ or less than 80tons |
| Side wall thickness (mm ) | 6mm Q235 steel |
| Bottom plate thickness(mm) | 8mm /Q235 steel |
| Lifting system | Full set of Hyva (FC214-5-07130) Hydraulic Lifting Cylinder |
| Chassis |
| Main Beams | Height:500mm Upper plate: 16mm Middle plate: 8mm (2-in-1 or 3-in-1 plate) Lower plate: 18mm Material :Q345B steel |
| Axle | 3 axles, FUWA/HUAJING brand 16tons per axle |
| Landing Gear | JOST (D200T) or Chinese brand 28T |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension/ America type / |
| Leaf Spring | 90(W)mm×13(Thickness)mm×10 layers |
| Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; 45L air tank |
| Rim | 9.00-22.5/8.00-20/8.5-20 China Brand |
| Tire | /12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Various tire brands are available. |
| ABS | Optional |
| Painting | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Accessories | One standard tool box |
| Shipping Terms | By Bulk Cargo or RORO The trailer size can be designed according to your special requirements. You can choose a 6×4 model truck for use with your rear dump semi |
