Driving type | 6x4 | ||
Cabin | HOWO 7 standard cab (no sleeper); 4-point air suspension and shock absorption; new style high back seat; Germany tech. VDO dash board; radio with USB; 4 way adjustable wheel; 4th generation air conditioner with LED light; sun visor; electronic controlled window/door. | ||
Engine | Model | WD615.69 | |
Feature | Diesel, 4-stroke direct injection, 6 cylinder in line, inter cooling, turbo-charging. | ||
Bore stroke (mm) | 126x130 | ||
Displacement (L) | 9.726 | ||
Power | 336hp/247kw | ||
Rated speed (rpm) | 2200 | ||
Torque (N.m) | 1350 | ||
Emission | Euro 2 | ||
Gearbox | Model | HW19710 double middle axle | |
Shift mode | Manual 10 forward 2 reverse | ||
Torque (N.m) | 1900 | ||
Rated speed (rpm) | 2600 | ||
First shift ratio | 14.284 | ||
Axle | Front | 9ton HR9 steering axle with disc brake | |
Rear | 16ton double reduction constructing axle | ||
Dump body | Dimension (mm) | 5800x2300x1500 | |
Thickness (mm) | Bottom: 8 Front: 6 Side: 4 | ||
Cubage (m³) | Approx 20 | ||
Lifting system | HYVA hydraulic front lifting HW50 PTO | ||
Steering | ZF 8118 Left hand drive | ||
Tyre | 12.00R20 radial tyre 10+1 spare | ||
Clutch | 430 Diaphragm type, single dry frictional disc, hydraulic boosting | ||
Fuel tank | 300L aluminum alloy | ||
Overall Dimension (LxWxH) | 8614x2496x3170 | ||
Wheel base (mm) | 3825+1350 | ||
Curb weight (kg) | 12250 | ||
Front overhang/Rear overhang (mm) | 1500/1939 | ||
Approach angle/Departure angle (°) | 19/13 | ||
Max speed (km/h) | 75 | ||
