| Traction type | 6×4 | |
| Drive System | LHD | |
| Cabin | F3000 Flat Cabin, one sleeper, Air Conditioner | |
| Engine | Brand | WEICHAI |
| Model | WP10.380E32 EGR | |
| Rated power | 380hp | |
| Engine displacement | 9.726 liters | |
| Gearbox | FAST 16 Speeds (16JSD200T) | |
| Clutch | 430 Diaphragm type | |
| Steering | ZF technology | |
| Axle | Front | 9.5 Ton Man axle |
| Rear | 16 Ton MAN double reduction axle, ratio:5.92 | |
| Max. running speed (km/h) | 77 | |
| Tire | 12.00R20 | |
| Fuel tank | 400L | |
| Kerb weight (kg) | 12100 | |
| Total mass (kg) | 25000 | |
| Wheel base (mm) | 3575+1400 | |
| Overhang (mm) (front/rear) | 1525/1530 | |
| Track (mm) (front/rear) | 1939/1860 | |
| Approach / departure angle(°) | 20/20 | |
| Dump body | Size | 5400x2300x1500(18.6m3) |
| Thickness | Floor 8mm, side 4mm | |
| Lifting system | Middle lifting | |
| Overall dimension | 8330x2500x3450mm | |
