1. Company profile

Xinxiang Hundred Percent Electrical & Mechanical Company is the material trolley manufacturer in China which takes the material trolleys the leading product. Our company has acute insight about the market trend of the material trolley, and our technology department reseaches and develops continuously new products according to the market demand.



2. Product detailed information

1)Working principle

KPC series' material trolley is powered by the sliding line. It conducts AC 380V sliding line directly into the AC electrical control system of the material trolley to let it start, stop, go forward and backward and so on. The trolley gets power from the slider of the safe sliding line which is moved by the trolley's running. The sliding line can be installed between the two rails' channel or in the channel outside the track. You can add boards on the channel for your safety and convenience. The operation system is low voltage 36V. The trolleys use motor drive and have automatic brake device. The trolleyt's transmission system is composed of the motor, the gear reducer and wheels.

2) Products parts

a. Electrical appliance box
b. trolley frame
c. remote controller or handle box
d. AC motor
e. gear reducer
f. sliding wire
g. wheel
h. alarm lamp




3) Advantages

a. Low trolley's height
b. Security and convenience
c. Powered by the sliding wire
d. Can be used frequently
e. The operation system is low voltage 36V power.
f. Simple structure, low cost and not so strict requirement on the construction of the rails

4) Applications

KPC series' material trolley is suitable to be used in the bad environment, for example, high-temperature condition. And it is the first choice for transferring materials from one workshop to another. This series material trolley is suitable for the conditions of short running distance(≤ 50m), high frequency, low trolley's height and assembly line works.



Technique Parameter

Type&specification	KPC-80T
Table dimension(mm)	6000*2600*800
Wheel base(mm)	4700
Wheel diameter(mm)	600
Wheel quantity	4
Rail inner gauge(mm)	1800
Running speed(m/min)	20
Motor power(kw)	7.5
Rated load(t)	80
Reference weight(t)	12.1
Max wheel load(kN)	278.4
Ground clearance(mm)	75
Recommended rail model	p50

Our Customer



Our Certificate



Production Supply Scope

Product Name	Model No.	Power Supply Mode	Load Capacity	Other Items	Usage
Rail Transfer Cart	KPD	Conductor Rail	Load range 1-300ton, can be customized per client demand	Running distance	Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc
Battery Powered Transfer Car	KPX	Battery		Using frequency
Motorized Transfer Trolley	KPJ	Cable Drum		Running distance
Busbar Powered Handling Cart	KPC	Busbar		Working shop
Towed Rail Trailer	KP	Tractor	1-100t	Working shop
Steerable Towed Car	BWT	Tractor	Load range 1-50t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded.	Working environment
Trackless Handling Machine	BWP	Battery		Working path

After-sale service

In the warranty period, if our product has any problem or can't work normally, we can support you repair technology or replace relevant parts for you.

According to the user's actual condition, design the auxiliary device or foundation drawing for free, and offer the technical service and drawing material. Guide the customer to install and debugging of the trolley until making customer satisfied.
