Professional Supply Vacuum Fecal Suction Truck with 13000L Tank

Professional Supply Vacuum Fecal Suction Truck/ Sewage Suction Truck With 13000L Tank

Technical Specifications of the HLQ5163GXE Fecal Suction Truck

Item		unit	parameter
Product Name			HLQ5163GXE fecal suction truck
Chassis model			EQ5160GKJ
Engine power		hp	180
Overall dimensions		mm	7800×2470×3150
	Tank capacity	L	13000
	Sucking depth	m	6
	Net weight	kg	7805
	Tank dimensions	mm	5100×2350×1500
	Wheel base		4700
	Front/rear overhang		1205/2095
	Approach/departure angle	°	25/18
Exhaust/hp		ml/hp	5900/190
Max speed		km/h	90
Tire specification		10.00-20	Engine type	YC6J180-33
Traction system		4×2	Transmission	6 Forward,1 Reverse
Number of axles		2	Electric system	24v
Operation control system		Power steering	Allowable passengers in cab	3
Front axle 5 tons, rear axle 10 tons, beam 250mm with double
Tank Equipment		vacuum pump Sucking depth <= 6m (rating rotate speed=1400r/m,min rotate speed>800r/m, , vacuum>500mmHg, clockwise) Maximum depssion created by vacuum pump&colon; 0.05 MPa Vacuum pump capacity&colon; 60 m3/h Tank filling speed&colon; not less than 30 m3/h Tank discharge speed (by self-flow)&colon; 10 min
Cabin Equipment		Windshield wiper Lockable doors Air-conditioner, cabin heater Outside rear view mirrors AM / FM radio Standard set of front, rear and side lights Standard set of indicators and gauges
Engine		DongFeng Commins diesel engine (Euro III)
Production cycle		10 days
Warranty		12 month, from the date of supply
1 set of spare parts consumables for one (1) year		- Air filter set (includes all filters required for air intake)&colon; 2 pcs. - Engine oil filter&colon; 2 pcs. - Fuel system filter set (includes all filters for fuel system and all required seals)&colon; 2 pcs.

WuhanYueruixiangTechnologyCo.,Ltdisaprofessionalsupplierofconstructionmachineryandagriculturemachinery,WearelocatedinWuhanCity,Hubeiprovince,China.

OurmainproductsincludesConstructionmachinery:Wheelloader,skidsteerloader,Forklift,roadroller,bulldozer,motorgrader,excavator,platecompactor,rammer,concretecutter,ect.

AndAgriculturemachinery:Tractorsandfarmingimplements.

Welcometocontactwithusatanytime.
