High Quality Overheight Container for Transporting Container

High quality Overheight Container for Transporting Container

1:Product Description
This spader is suitable the double-link portal crane or jib crane, and the main paraments is as follows:
1, Suitable for 20`-40` telescopic spader
2, Capacity under spader: 40t
3, lifting capacity of four lugs: 10t*4
4, Dead weight: ~7800
5, dead weight of rotation hook: 1600kg
6, Power: AC380V(3phase)50Hz or 60Hz
7, IP class: IP55
2:technical data










3:Packing and Shipping:





4:Our Services:
Actasagoodadviserandassistantofclient,wecanhelpthemtogetrichandgenerousreturnsontheirinvestment.

1.Pre-saleservices:

a:Designcustomisedprojectforclients.

b:Designandmanufctureproductsaccordingtoclientsspecialrequirement.

c:Traintechnicalpersonnelforclients.

2.Servicesduringthesale:

a:Helpclientstofindreasonablefreightforwarders aheadofdelivery.

b:Helpclientstodrawsolvingplans.

3.After-saleservices:

a:Assistclientstopparefortheconstructionscheme.

b:Installanddebugequipment.

c:Trainthefirst-linoperators.

d:Examineequipment.

e:Takeinitiativetoeliminatethetroublesimmediately.

f:Providetechicalexchanging.
5.PartsIntroduction
1.LeverForOperatingRope
2.20'&40'HeavyDutyContainerSpaders
3.Semi-AutomaticorManualOperation
4.ExtraLargeLiftingRings180*340mm180*340mm
5.ActuationSpring
6.SpringSupport
7.OperatingHandle
8.Twistlock
9.ActuationGearForSemi-AutomaticOperation

6.SpaderCharacteristics
1.Thespaderadoptsbox-typeendbeam,sothestructureisstable.Thetwistlockisleakproofstructure,whichprotectsthepartsfromrusting
2.Fourhoistpointsstructure,whichlightenthedeadweightofthespader,andenhancethestabilityofthespader.
3HS20'/HS40'spaderadoptHeavyhammertypesemi-automatictwistlock,manpowertoturnthepinisnoneedanymore,whichhighlyimprovetheworkefficiencyandsafetyonspot

7.SafetyTest
1.Eachspadershouldbecarriedout150%staticloadtestbeforedelivering.
2.Alltheliftingeyesshouldbecarriedoutsafetytest.
3.Eachtwistlockshouldbecarriedout25tsafetytest.


8.SafetyProtection
.Whenthespaderliftscontainer,theloadshouldnotexceedthemax.SWL.
2.Whenusingthespader,usingdesignfunctiononly.
3.Personshouldn'tstandundertheliftingspader.
4.Afteroperation,pleasecheckiftherearedamagesonthespader,iffastenersloose.Ifso,pleaserepairtimely.


9:RepairandMaintenance

1.Twistlock
1.Eachtwistlockshouldbelubricated(GreaseZG-3),lubricatethespaderhalfayear.
2Hingepointoftheconnectingrodshouldbelubricatedfrequently.
3.Afteroperation,pleasecheckiftherearedamagesonthetwistlock.
Bearingblockoftheconnectingrodshouldbelubricatedfrequently.

2.1.After50hours'and250hours'operation,allthefastenersshouldbefastenedagain,andallthelubricatingpartsshouldbelubricated.
2.After100hours'operationorlifting1500containers,checkifallthescrewsandfastenersarefastened.Ifloose,pleasefastenagain.
3.After1000hours'operationorlifting15000containers,allthelubricatingpartsshouldbelubricated.
4.After1500hours'operationorlifting25000containers,thetwistlockstructureshouldbechecked.
aDisassembleallthefourtwistlockstructures.
b)Ifanyproblem,pleasereplacedaccordingly.
c)Washingalltheparts.
d)Installthefourtwistlockstructures.
5.After3000hours'operationorlifting50000containers,thetwistlockstructureshouldbechecked,iftherearecracksorotherfaults,pleasereplacetimely.
After6000hours'operationorlifting100000containers,pleasereplacethetwistlockstructure.

10:FAQ:
Before you send us an inquiry about container spader, please let us know some information as following:

1:What is lifting capacity of spader?
What is type of spader? Semi automatic container spader, New I type spader, motor spader, hydraulic telescopic spader or electro telescopic spader?

2:If what you need is telescopic spader, please confirm it is hydraulic telescopic or electric telescopic?

3:What is the using temperature of spader?

Technical Specification

.Scope of supply
HS20 /HS40 GBM..,
One unit 20'/40' GBM automatic container spader. It includes 4 steel wire ropes, which have rigging rings at the end of the steel wire ropes. The ends that connect with the crane have a concentrated ring.

Item	20'	40'
Max. SWL	≈ 35 t	≈40 t
Dead Weight	≈1.8t	≈3.1t

. Overall Dimensions

Item	20'	40'
(): Distance between lock centers(length)	≈ 5853 mm	≈11985 mm
(): Distance between lock centers(width)	≈ 2260 mm	≈2260 mm
: Overall Length	≈ 6058 mm	≈12188 mm
: Overall Width	≈ 2610 mm	≈2610 mm
: frame Height	≈ 636 mm	≈731 mm

. Technical Parameter

Item	20'	40'
Dia. of pssed wire rope slings	32 mm	36 mm
Length of pssed wire rope slings	3.5m per piece (4 pieces for each set)	8.5m per piece (4 pieces for each set)
Steel frame	Material Q345B	Material Q345B
ISO Standard Fixed Twist Lock	Material 42CrMo	Material 42CrMo
Twist Lock Device	Finish the Twist locks action via semi-automatic Elastic lasso	Finish the Twist locks action via semi-automatic Elastic lasso

. Surface Treatment & Painting
1.
Flame dirt-remover, and then shot blasting.

2. 40µm,,80µm/40µm.
Primer coating (Epoxy resin paint) app. 40µm
Middle (Epoxy resin paint) app. 80µm
Top paint (Polyurethane paint) app. 40µm.

(),,
The top coat paint color is yellow. There is scutcheon with the main specifications, manufacture date and exfactory number.

. Technical documents
,:
When delivering, the seller provides:
drawings of the spader& quick-wear parts
()Operation Manual
Certificate of Quality

. Parts Introduction
1. Lever For Operating Rope
2. 20'&40'Heavy Duty Container Spaders 20'&40'
3. Semi-Automatic or Manual Operation
4. Extra Large Lifting Rings 180*340mm 180*340mm
5. Actuation Spring
6. Spring Support
7. Operating Handle
8. Twist lock
9. Actuation Gear For Automatic Operation

. Spader Characteristics
1. ,,,.
The spader adopts box-type end beam, so the structure is stable. The twist lock is leak proof structure, which protects the parts from rusting
2. ,,.
Four hoist points structure, which lighten the dead weight of the spader, and enhance the stability of the spader.
HS20'/ HS40',,,,.
HS20'/ HS40' spader adopt Heavy hammer type semi-automatic twist lock, manpower to turn the pin is no need any more, which highly improve the work efficiency and safety on spot

. Safety Test
1. 150%.
Each spader should be carried out 150% static load test before delivering.
2. .
All the lifting eyes should be carried out safety test.
3. 25.
Each twist lock should be carried out 25t safety test.

.Safety Protection
1. ,.
When the spader lifts container, the load should not exceed the max. SWL.
2. ,.
When using the spader, using design function only.
3. .
Person shouldn't stand under the lifting spader.
,,.,.
After operation, please check if there are damages on the spader, if fasteners loose. If so, please repair timely.


.Repair and Maintenance

() Twist lock
1. (ZG-3),.
Each twist lock should be lubricated (Grease ZG-3), lubricate the spader half a year.
2. (ZG-3).
Hinge point of the connecting rod should be lubricated frequently.
3. ,.
After operation, please check if there are damages on the twist lock.
(ZG-3).
Bearing block of the connecting rod should be lubricated frequently.
()
1. 50250,,.
After 50 hours' and 250 hours' operation, all the fasteners should be fastened again, and all the lubricating parts should be lubricated.
2. 1001500.,.,,.
After 100 hours' operation or lifting 1500 containers, check if all the screws and fasteners are fastened. If loose, please fasten again.
3. 100015000,.
After 1000 hours' operation or lifting 15000 containers, all the lubricating parts should be lubricated.
4. 1500,25000,.
After 1500 hours' operation or lifting 25000 containers, the twist lock structure should be checked.
a)
Disassemble all the four twist lock structures.
b) ,.
If any problem, please replaced accordingly.
c) .
Washing all the parts.
d) .
Install the four twist lock structures.
5. 3000,50000,.(),.
After 3000 hours' operation or lifting 50000 containers, the twist lock structure should be checked, if there are cracks or other faults, please replace timely.
6000.100000,,.
After 6000 hours' operation or lifting 100000 containers, please replace the twist
lock structure.

Pics reference





4:Will you match a rotator with the telescopic spader?
