High quality Overheight Container for Transporting Container
1:Product Description
This spader is suitable the double-link portal crane or jib crane, and the main paraments is as follows:
1, Suitable for 20`-40` telescopic spader
2, Capacity under spader: 40t
3, lifting capacity of four lugs: 10t*4
4, Dead weight: ~7800
5, dead weight of rotation hook: 1600kg
6, Power: AC380V(3phase)50Hz or 60Hz
7, IP class: IP55
2:technical data
3:Packing and Shipping:
Nude
4:Our Services:
Actasagoodadviserandassistantofclient,wecanhelpthemtogetrichandgenerousreturnsontheirinvestment.
1.Pre-saleservices:
a:Designcustomisedprojectforclients.
b:Designandmanufctureproductsaccordingtoclientsspecialrequirement.
c:Traintechnicalpersonnelforclients.
2.Servicesduringthesale:
a:Helpclientstofindreasonablefreightforwarders aheadofdelivery.
b:Helpclientstodrawsolvingplans.
3.After-saleservices:
a:Assistclientstopparefortheconstructionscheme.
b:Installanddebugequipment.
c:Trainthefirst-linoperators.
d:Examineequipment.
e:Takeinitiativetoeliminatethetroublesimmediately.
f:Providetechicalexchanging.
5.PartsIntroduction
1.LeverForOperatingRope
2.20'&40'HeavyDutyContainerSpaders
3.Semi-AutomaticorManualOperation
4.ExtraLargeLiftingRings180*340mm180*340mm
5.ActuationSpring
6.SpringSupport
7.OperatingHandle
8.Twistlock
9.ActuationGearForSemi-AutomaticOperation
6.SpaderCharacteristics
1.Thespaderadoptsbox-typeendbeam,sothestructureisstable.Thetwistlockisleakproofstructure,whichprotectsthepartsfromrusting
2.Fourhoistpointsstructure,whichlightenthedeadweightofthespader,andenhancethestabilityofthespader.
3HS20'/HS40'spaderadoptHeavyhammertypesemi-automatictwistlock,manpowertoturnthepinisnoneedanymore,whichhighlyimprovetheworkefficiencyandsafetyonspot
7.SafetyTest
1.Eachspadershouldbecarriedout150%staticloadtestbeforedelivering.
2.Alltheliftingeyesshouldbecarriedoutsafetytest.
3.Eachtwistlockshouldbecarriedout25tsafetytest.
8.SafetyProtection
.Whenthespaderliftscontainer,theloadshouldnotexceedthemax.SWL.
2.Whenusingthespader,usingdesignfunctiononly.
3.Personshouldn'tstandundertheliftingspader.
4.Afteroperation,pleasecheckiftherearedamagesonthespader,iffastenersloose.Ifso,pleaserepairtimely.
9:RepairandMaintenance
1.Twistlock
1.Eachtwistlockshouldbelubricated(GreaseZG-3),lubricatethespaderhalfayear.
2Hingepointoftheconnectingrodshouldbelubricatedfrequently.
3.Afteroperation,pleasecheckiftherearedamagesonthetwistlock.
Bearingblockoftheconnectingrodshouldbelubricatedfrequently.
2.1.After50hours'and250hours'operation,allthefastenersshouldbefastenedagain,andallthelubricatingpartsshouldbelubricated.
2.After100hours'operationorlifting1500containers,checkifallthescrewsandfastenersarefastened.Ifloose,pleasefastenagain.
3.After1000hours'operationorlifting15000containers,allthelubricatingpartsshouldbelubricated.
4.After1500hours'operationorlifting25000containers,thetwistlockstructureshouldbechecked.
aDisassembleallthefourtwistlockstructures.
b)Ifanyproblem,pleasereplacedaccordingly.
c)Washingalltheparts.
d)Installthefourtwistlockstructures.
5.After3000hours'operationorlifting50000containers,thetwistlockstructureshouldbechecked,iftherearecracksorotherfaults,pleasereplacetimely.
After6000hours'operationorlifting100000containers,pleasereplacethetwistlockstructure.
10:FAQ:
Before you send us an inquiry about container spader, please let us know some information as following:
1:What is lifting capacity of spader?
What is type of spader? Semi automatic container spader, New I type spader, motor spader, hydraulic telescopic spader or electro telescopic spader?
2:If what you need is telescopic spader, please confirm it is hydraulic telescopic or electric telescopic?
3:What is the using temperature of spader?
4:Will you match a rotator with the telescopic spader?
Product Image
