Skeleton Frame Truck Chassis Semi Trailer for 20FT 40FT Container

Skeleton frame truck chassis semi trailer for 20ft 40ft container

TECHNICAL HIGHLIGHTS:

• Carrying for dry cargos, 1*40ft or 2*20ft containers
• High Quality Body
• BPW, FUWA or Certificated Chinese Axles
• ABS brake system
• JOST or Chinese brand parking leg and king pin
• Air and Mechanical Suspension
• Strength Chassis Construction

Specifications:

Item	Unit	Quantity	Notice
Overall dimension	detail according to the drawing
Axle	piece	3	FUWA-13T
Tyre	piece	12	11R20-16PR,Triangle Tire without spare tire
Rim	piece	12	8.0-20
Leaf spring	piece	6	90width*10pieces*12 thickness
Braking system	set		2 line air braking system with air tank ,emergency relay valve,braking chambers and mechanical slack adjusters.
Electricalsystem	set	1	24 volt electrical system.7 pin electrical connector.parking .stop,reverse,number plate and indicator lights.rear lights conform to European standard,rear front and side reflectors
Suspension	set	3	Standard CIMC Suspension
Relay valve	whole vehicle	1	WABCO
Landing gear	pair	1	JOST C200
Kingpin 2"	piece	1	50# Welded
Tie-in	piece	2	haldex
Chamber	piece	2	stored chamber 2 units T30/30
Upper and lower wing plates			14/16mm,width146mm, using the highly quality Q345 steel,
Twist locks		12	can load 1*40ft,2*20ft,1*20ft container
Main beam			height: 500mmwebplate:6mm using the highly quality Q345 steel
Reflectors			Red triangle reflectors at the rear of the trailer andon side
Spare tyre carrier		2	standard
Color			according to required on customer

Details of the 40ft skeletontrailer for your reference

Customized:
1-trailers for 20ft,30ft,40ft,45ft,48ft,50ft,53ft container shipping
2-flatbed or skeleton chassis type
3-Main beam:500mm height
4-material of the main beam: Q345
5-Suspension: spring suspension, Rigid, single point, bogie or air suspension
6-Axles number: 23 4axles.
8-Jost landing gear, FUWA axles and Tri-angle tires
9-extendable or sliding type optional

TRAILER MANUFACTURING

The trailers production is based on modern technology and processes.
Flow from the production
The DFT production
Laser cutting
Flame cutting
Robot welding
Bolts and nuts
metallization
Blasting
...nothing is left to chance to ensure the semi trailers quality.

Buying Guides
1**You please send us your enquiry;
2**We shall reply you with the quotation within 12 hours;
3**We negotiate on the configuration that you need;
4**Confirmation of the tech data →sign contract (P/I) →30% deposit (or L/C issuing)→ production;
5**Manufacturing process updated news →completing production;
6**Balance payment →ex works →shipment →custom clearance →A/S service for 1year.
