Liugong Concrete Mixer Truck YZH5253GJBDL

LiuGong concrete mixer truck YZH5253GJBHW

1. Driving type: 6*4

2. Drum volume: 13.4m3

3. Engine power 247KW China III emission

CHASSIS

Chassis Model DELONG SX5255GJBJR364

Emission Stage China 3

Engine Power 247KW

Engine Displacement 9.726L

Driving Type 6× 4

Wheelbase 3625+1350mm

Max. Running Speed 77km/h

Min. Turning Radius 19 m

Brake type Air pssure of double loop

Truck loading capacity 12070 kgs

DRUM

Drum material Baosteel B520JJ

Drum volume 13.4 m³

Drum loading capacity 8 m³

Drum agitating volume 5 m³

Material charge speed ≥ 3 m³ /min

Material discharge speed ≥ 2.7 m³ /min

Material discharge control Manual

Drum remnant ratio of discharging ≤ 0.5%

Drum rotating speed 0-18 (r/min)

Drum tilt angle 13°

HYDRAULIC SYSTEM

Hydraulic pump Sauer KPV23-674R

Hydraulic pump type Piston pump

Hydraulic motor Sauer KMF23-516-50

Speed reducer Sauer TMG61.2

Hydraulic circuit type closed circuit cycle

Hydraulic tank capacity 20L

Water tank capacity 450 L

DIMENSIONS&WEIGHT

Overall Length 8850mm

Overall Width 2496 mm

Overall Height 3780 mm

Truck gross Weight 25000 kgs

Truck net weight 12800 kgs
