MAIN DEscriptION | |||
Overall Dimensions | 9780mm*2496mm*3990mm(L*W*H) | ||
Tare Weight | 13950kg | Payload | 28000kg |
Front Overhang | 1500mm | Rear Overhang | 2880mm |
Wheelbase | 4000mm+1400mm | Track (F/R) | 2022mm/1830mm |
CHASSIS | |||
Chassis Brand | SINOTRUK HOWO | ||
Chassis Model | ZZ1257N4048W, driving type 6x4 | ||
Cab | HW76, left hand drive, air-conditioner, one sleeper | ||
Engine | SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L | ||
Transmission | HW19710, No. of speeds: 10 forward 2 reverse | ||
Steering | German ZF8098, turning system pssure 18MPa | ||
Rear Axle | HC16 tandem axle, rated load 2x13ton, ratio 5.73 | ||
Wheels and tires | Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel | ||
Brakes | Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compssed air operating on rear wheels; Auxiliary brake: Engine exhaust brake | ||
MIXING SYSTEM | |||
Mixing Volume | 10cbm | ||
Water Tank Volume | 440L | ||
Hydraulic Pump | Brand: ARK, Italy | ||
Motor | Brand: ARK, Italy | ||
