Xcm 37m Concrete Pump Truck Hb37b

XCM 37m Concrete Pump Truck Hb37b

Concrete Pump truck has features of good maneuverability, short pparation time, high efficiency, good construction quality, less pollution of the environment. It is widely used in large-scale infrastructure constructions such as bridge, electric power plant, steel works, water disposal plant and high-rise building constructions.

Concrete Pump truckcomprises superstructure and chassis. Components imported from German WAITZINGER Company , multi-way valves imported from German HAWE Company and center pumping mechanism with technology of GermanPM Company available in the superstructure and CXZ51Q chassis made by ISUZU Japan as well as drive system with 4-series oil pump contribute to its high drive ability and reliability.
Specifications:
1. Concrete Pump truck HB37B
2.6WF1 original Engine, more powerful
3.ISUZU chassis Japan
4.Reach height:37.4 m

No.	Item	Unit	Parameter
1	Max. speed	km	90
2	Min. turning diameter	m	18.4
3	Brake distance	m	7
4	Approach angle	°	31
5	Departure angle	°	12
6	Chassis model		CXZ51Q ( Japan )
7	Total weight	kg	28150
8	1st axle load	kg	6780
9	2nd, 3rd axle load	kg	21220
10	Engine model		6WF1
11	Max. Engine power	kW	287
12	Max. Engine torque	N.m	1862
13	Max. grade-ability	%	38
14	Fuel consumption limit	L/100km	34
15	Outline dimensions (L´ W´H	mm	11990´2490´3900
