Sany 43m Concrete Pump Trucks (SYG5310THB)

Sany 43M Concrete Pump Trucks(SYG5310THB)

5 sections RZ form Boom, highest flexibility;
X outrigger, easy and fast operation, OSS function;
High performance SYMC control unit and fine definition SYLD display;
Automatic retraction of concrete piston, easy replacement and maintenance friendly;
Electro-hydraulic buffer, differential pssure induction, open loop hydraulic system, low operation temperature; Less impact and high reliabllity.


Quick Details
Condition:
New
Power Type:
Diesel
Place of Origin:
Hunan, China (Mainland)
Brand Name:
Sany
Model Number:
SYG5260THB
Power(W):
265kw
Weight:
27640kg
Dimension(L*W*H):
11800*2500*3380mm
Certification:
ISO9001
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Chassis model:
BENZ Actros 3341
Engine type:
OM501LA. III / 17
Engine power:
300kW/1800rpm

Boom&outrigger specifications	Dead weight		27495kg
	Vertical reach		38m
	Horizontal reach		33m
	Reach depth		21.3m
	Unfolding reach		8.3m
	1st section	Length	8700mm
		Articulation	92°
	2nd section	Length	7860mm
		Articulation	180°
	3rd section	Length	8050mm
		Articulation	260°
	4th section	Length	8390mm
		Articulation	245°
	Rotation		360°
	Outrigger spad L-R-Front		6200mm
	Outrigger spad L-R-Rear		7160mm

Length	11520mm	11750mm
Width	2500mm
Height	3990mm	3970mm
Dead weight	31490kg
