Forland Small 4cbm Concrete Mixer Truck

Forland Small 4cbm Concrete Mixer Truck

Product name	Forland Small 4cbm Concrete Mixer Truck for Sale
Model	CLW5090
Drive model	4×2
Wheelbase	3600mm
mixer truck Dimensions	6460×2255×3300mm
Engine	Renault :CA4DC2-12E3, 130hp,4 Cylinder, Turbo Diesel,130HPs/2100RPM, Discharge 4000ml, Euro 3emission standard, Air-air cooling ,electrical control High Pressure Common Rail diesel engine.
Suspension	Leaf spring 10/12+9
Brakes	Service brake: Two-circuit air pssure braking.
	Parking brake: Air pssure braking
	Exhaust brake: Air pssure braking
frame section(mm)	300×90×(8+6)
Tyres	8.25-20
Electrical system	Alternator 28V/80A,Batteries 12V/175Ah
Fuel tank capacity	300L, Steel tank.
Curb weight	5890kgs
Axles loading capacity	5,000kgs
Cab	Tilt cab mechanical hydraulic overturn, left-hand drive, electrical window, Central locking
Accessories	Tool box, Air conditioner, cold boot, inter axle differential
Max. speed	85km/hour
Tank Geometric volume	6m3
Valid mixing tank volume	3m3
Type of tank board	The mixing drum is made of 5mm thick Mn steel, and the ends of drum are 6mm thick.
Tank wielding	automatic welding
others	China famous brand motor; Changzhou brand reducer, 350L pneumatic water storage tank
Feed rate	≥3 m3 /min
Discharge rate	2 m3/min
Residual rate of discharge	<0.7%
Work condition	City transport concrete

about us
We CLW Heavy Industry Co., Ltdare aprofessionalmanufacturerand exporter which is concerned with the design, development and production of more than300kinds of trucks, semi-trailers, and storage tanks.We also providespare partsfor the products separately.

All of our products comply can reach theinternational quality standardsand are greatly appciated in avariety of markets around the world.

1. CLW Heavy Industry Co., Ltd, which was appointed bythe Development and Reform Committee of China, is afamous manufacturer producing all kinds of special trucks for municipal &environmental construction, petrol &medicals, container, and semi-trailer having nearly15 yearswholesaler experience in producing truck.

2.Our company hasindependent export rightand has amount of clients overseas includingAfrica, North America, Middle East, Australiaand so on.The export turnoverhas reached25million dollars.

3.Our company hasgood after-sales service,solid technology,flawless inspectionfor our dear customers.


CLW Heavy Industry Co., Ltd also provide products as follows:

1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck/ Water Tank Truck/ Water Sprinkler Truck/Water Tanker
3. Truck with crane /Truck mounted crane
4. Dump Truck /Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck /Fire Truck /Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Blasting equipment transporter/ Refrigerated truck
8. Fecal suction truck /Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Selfloading garbage truck, garbage compactor truck,sealed garbage truck
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer (flat bed trailer/ skeleton trailer/ dump semi trailer/ side wall trailer/ low bed trailer/ van container trailer/ warehouse trailer, etc.)
16. Spare parts/Accessory for above products

FAQ

1. Q: How about the quality of trucks of your factory?
A: Our trucks getISO 9001:2008 and CCC, B&V and other relatedcertificates. The chassis and spare parts come from the original manufacturers with anti-fake label.

2. Q:How many years of your company's service, especially after-sale service?
A: CLW Heavy Industry Co., Ltd has been in this field fornearly 15 yearsand has strong production and distribution capability, we can produce your products in 15 working days. We offer 1year after-sale service.

3. Q:Is there any advantages of your price?
A: CLW Heavy Industry Co., Ltd is one of the most important suppliers ofSinotruk, Shacman, Dongfeng, FOTON and FAW,which provides guarantees for reasonable price and goodquality.

4. Price term:FOB, CIF.

5. Payment: 30% deposit after order /confirm/iation, 70% balance should be paid before delivery. All are byT/T, L/C.

6. Delivery time:25 working daysafter payment is received.

7. Standard Steering:Left-hand drive,if you need Right-hand drives, please inform us, will make special order for you.
