FUNCTIONS
1. This series co
ncrete mixer semi trailers are mainly used in co
nstruction transportation for concrete/ cement.
2. The volume varies widely from 5cube meters to 40 cube meters, we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different to
nnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc.
5. The tanker body is made from Q235B carbon steel.
BRIEF INTRODUCTION TO OUR FACTORY
Phillaya internatio
nal trading Co., Ltd, a special vehicle manufacturing corporation with the professio
nal experience more than 15 years, certified by the Chinese government manufacture,
Majored in semi trailer, special vehicle manufacture, our products are mainly exported to
Philippine, Bangladesh, Thailand, Myanmar, Vietnam, Nigeria, Russia, Mongolia, Congo, Kenya, Tanzania, etc...More than 20 countries
SERVICE WE PROMISED FOR EACH ITEM FROM OUR FACTORY
1.3C&ISO Agreement, 1 Year Guarantee Term, Main-beam Lifetime Promise.
2. Small Order Can Be Accepted.
3. Any Color & Logo Available
4. The Product Dimension + Specifications Can Be Designed As Your Needs
DEALING PROCESS
1. Send us inquiries on your desired product / mdel through our co
ntact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Co
nfiguration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updat
ed news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.
WELCOME TO VISIT OUR FACTORY, WE SHALL PICK YOU UP FROM THE AIRPORT. WISH THE LONG-NEW MUTUAL BENEFIT & BUSINESS RELATIo
nSHIP CAN BE BUILT BY OUR JOINT EFFORTS
| 8CBM ConCRETE MIXER SEMI TANK TRAILER |
| Tare Weight | 10800kg | Overall Length | 9995mm |
| Overall Width | 2495mm | Overall Width | 3780mm |
| Tank |
| Capacity | 8CBM |
| Mixing Tanker Sloping Angle | 14, 12,10 degree |
| Mixing Tanker Revolving Speed | 12-20 (r/min) |
| Key Accessories |
| Engine | Diesel engine or electrical motor |
| Hydraulic Pump | American Eaton or Italian TOP hydraulic pump |
| Hydraulic Motor | American Eaton or Italian TOP hydraulic motor |
| Gear Box | American Eaton or Italian TOP gear box |
| Chassis | Skeletal Chassis with special designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm; Bottom Flange 16mm,width 140mm. |
| Axles | 2 axles, Fuwa |
| Suspension | Mechanical suspension/ |
| Leaf Spring | 8-piece leaf spring |
| King Pin | 2 Bolt-in King Pin |
| Landing Gear | Two-speed, manual operating, heavy duty landing gear |
| Tyre | 11.00-20, 12.00-20, 11.00R20, 12.00R20, 11R22.5, 12R22.5-Optional |
| Spare Tire | One set of spare tire including a carrier |
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks |
Others:
Other Size/dimension or configurations will be available by customeri-zation. |
