No. | Item | Unit | Parameter |
---|
1 | Max. speed | km | 90 |
2 | Min. turning diameter | m | 18.4 |
3 | Brake distance | m | 7 |
4 | Approach angle | ° | 31 |
5 | Departure angle | ° | 12 |
6 | Chassis model | | CXZ51Q (Japan ) |
7 | Total weight | kg | 28150 |
8 | 1st axle load | kg | 6780 |
9 | 2nd, 3rd axle load | kg | 21220 |
10 | Engine model | | 6WF1 |
11 | Max. Engine power | kW | 287 |
12 | Max. Engine torque | N.m | 1862 |
13 | Max. grade-ability | % | 38 |
14 | Fuel consumption limit | L/100km | 34 |
15 | Outline dimensions (Length´ Width ´Height) | mm | 11990´2490´3900 |
Technical Data for Pumping Operation
No. | Item | Unit | Parameter |
---|
1 | Theoretical output | m3/h | 138/90 |
2 | Max. delivery pssure | MPa | 8.7/13 |
3 | Reach height | m | 37.4 |
4 | Reach depth | m | 23.7 |
5 | Front outrigger transverse span | mm | 7280 |
6 | Rear outrigger transverse span | mm | 6600 |
7 | Outrigger longitudinal span | mm | 6860 |
8 | Delivery pipe diameter | mm | 125 |
9 | Remote control distance | m | 100 |
10 | Placing boom slewing range | ° | 370 |
[Company Information]XCMG is aco
nstruction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comphensive co
nstruction machinery manufacturer and influential multinatio
nal company. In 2015, we rank No.1 in China and No. 5in global heavy equipment industry.XCMG's co
nstruction machinery covers an asto
nishing range of equipment, including cranes, earth-movingmachinery, road machinery, excavators, co
ncrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comphensive product line, and offer customers complete solutions for co
nstruction equipment.Our other businesses include finance, leasing, and remanufacturing.
At psent, the power of my company's straight-arm crane is entirely from the hydraulic oil pssure, that is, through the high-pssure hydraulic oil to promote the cylinder piston reciprocating motion, or drive the hydraulic motor rotation makes the hydraulic winch and rotary mechanism rotation.
So, how do high-pssure hydraulic oil get? Each truck crane is equipped with ahydraulic pump when the vehicle chassis is matched, and the engine provides power for it. The chemical energy of the fuel can be co
nverted into the crankshaft of the engine to rotate the mechanical energy, and then the gearbox gear is rotated, and then the power is transmitted to the hydraulic pump through the power transmission of the gearbox. Therefore, the hydraulic pump can co
ntinuously pssurize the hydraulic oil For the high-pssure hydraulic oil, so as to provide power for the crane to achieve the lifting of the goods.
Competitive Advantage
My company's straight arm crane crane covers 1-25 tons 14 models 65 kinds of products, to meet avariety of conditions, with the lo
ngest arm of the largest to
nnage crane mature manufacturing technology, scientific research and development process, advanced Research and development technology, and co
nstantly have new products to market, to meet customer use.
My company's boom arm section with mature pentagonal, hexago
nal and octagonal, the latest generation of products with U-shaped arc arm body weight reduction, arm width of alarge deflection, stability and resistance to deformation Ability to improve, significantly enhance the lifting capacity.
The application of the sub-arm, sub-winch and vice-hook provides abasis for the rapid and large-scale operation of the crane light load and the high-altitude operation. The application of automatic hook technology saves time and effort when starting and ending crane operations, making it easy to operate easily.
Our company will offer you the high quality products with alow price, quick delivery,and professio
nal after-sale service.
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Unio
n (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What a
bout the delivery time?
A: 30 days after receiving the deposit.
4: What a
bout the warranty time?
A: 12 mo
nths after shipment or 2000 working hours, whichever occuts first.
5. What a
bout the Minimum Order Quantity?
A: The MOQ is 1pcs
