Xcm 35 Ton Mobile Truck Mounted Crane Price Qy35K5

Product Description
XCM QY30K5 truck crane
1. Outline dimensions: 12, 070X2, 500X3, 390mm
2. Total mass in travel state: 32.4ton
3. Engine model: SC8DK230Q3
4. Engine rated output: 206/2200kw/(r/min)
5. Engine rated torque: 1170/1400N. M/(r/min)
6. Engine max travel speed: 2200r/min
7. Max travel speed: 75km/h
8. Min. Turning diameter: 22m
9. Min. Ground clearance: 291mm
10. Approach angle: 19
11. Departure angle: 13
12. Braking distance(at 30km/h)10m
13. Max. Gradeability: 30%
14. Fuel consumption for 100km: 40L
15. Max. Total rated lifting load: 30ton
16. Min. Rated working radius: 3m
17. Turning radius at swing table tail: 3065mm
18. Max. Load moment
base boom: 1025kN. M
19. Outrigger extension distance
Longitudinal: 5.85m
Lateral: 6.0m
20. Lifting height:
base boom: 10.1m
Fully extended boom: 38.7m
Fully extended boom + jib: 47.6m
All kinds of truck crane: QY8D, QY12, QY16D, QY20B, QY25K, QY25K5, QY30K5, QY40K, QY50K, QY60K, QY70K, QY80K, QY100K, QY130K.
