| General Description | ||
| 1 | Driving type | 4*2,left hand drive |
| 2 | Overall Dimension | 7500×2470×3050 mm |
| 3 | Kerb weight | 6,300 Kg |
| 4 | Rated Payload | 10,000 Kg |
| 5 | Wheelbase (mm) | 4,500 mm |
| 6 | Fuel type | Diesel oil |
| 7 | Front/Rear axle | 3,600 /9,000 Kg |
| 8 | Tire | 9.00R20, 6+1 Pcs |
| 9 | Passengers | 3 |
| 10 | Volume of oil tank | 95 L |
| 11 | Gearbox | Six speed lever, 5speed forward with 1reverse, manual |
| Engine Description | ||
| 1 | Brand | Cummins /Howo /Sinotruck |
| 2 | Model | B190-33 |
| 3 | Displacement (L) | 5.9 L |
| 4 | Emission Standard | EURO 3 |
| 5 | Rated Power | 190 Hp |
| 6 | Maximum Speed | 95 Km/h |
| Concrete tank Description | ||
| 1 | Max Mixing Cubage | 8,000L |
| 2 | Feeding Speed (m3) | 4,500 L |
| 3 | Discharging Speed (≥m3) | 4,000 L |
| 4 | Max Rotating Speed (r/min) | 16 |
| 5 | Mixing Drum Obliquity (°) | 10 |
| 6 | Hydraulic Pump | Italian TOP089 |
| 7 | Water supply mode | Water pump; pneumatic pump |
