Marine Mooring Four Roller Fairlead

Marine Mooring Four Roller Fairlead
Marine Mooring Four Roller Fairlead, consistinng of vertical and horizontal rollers, can guide mooring ropes from any direction. Horizontal roller fairlead, also called universal rolelr fairlead, is usually located in the deck end, can greatly recuce the abrasion of mooring ropes for the rollers fixed around the fairlead.
1.Good wear and corrosion resistance.
3.Durable, long lifetime.
3.Provide CCS , BV , LR , BV etc Certificate.
4. Marerial: cast steel ZG230-450,Q235.
5.Surface: Blasting,Epoxy.
6.Customized service is available, Advanced equipment ,Strong consciousness in controlling quality.
We can supply roller fairlead, Fairleads with horizontal rollers according to JISF, DIN and GB standards . We can also make these products according to buyer's drawings.
Certificate:ABS,DNV,GL,RINA,BV etc.
Specification

Type	Wire Ø	A	B	C	D	E	F	G	H	I	K	L	weight(kg)
CFG2	12	180	100	650	80	446	170	10	465	253	125	356	90
CFG3	16	230	130	800	100	546	210	10	575	308	150	446	160
CFG5	20	250	130	900	120	626	250	15	655	363	175	506	280
CFG8	24	280	160	1000	140	716	290	20	730	423	215	576	394
CFG12	32	300	160	1200	180	836	366	25	855	518	260	676	860
CFG20	40	320	180	1350	245	1030	500	35	1045	660	335	830	1500
CFG32	48	400	250	1700	300	1236	610	45	1260	788	405	1016	2550

Quality Assurance and Service
1. Have acomplete rigorous management, production and inspection processes to control the quality and avoid detail mistake
2. Design and produce ability
3. Rigorous inspection including incoming inspection, flaw detection etc., and double check is amust.
4. Advanced factory facility ensure
5. Response to any inquiry within 24 HRS with design or efficient solution from our engineer or tech supporter.
6. Provide professional customization service according to client's requirements
7. on time delivery, as we have rigorous production schedule and profession follow-up process
8. Moderate price and professional service

If you have any question or inquiry, please feel free to contact us for more details.
