1.5m3 Auto Self Loading Concrete Mixer Truck with PLC Weighing System

1.5m3 Auto Self Loading Concrete Mixer Truck with PLC Weighing System
Self-loading concrete mixer feature combines self-loading,weighting,mixing and discharging,it can maximize and improve the job efficiency and reduce the production cost and time.

1.LOADING of Self Loading Concrete Mixer:
Thanks to its unique four bar linkage shovel,its easily manages all the loading operations of the aggregates with excellent pcision.
The blade fitted inside the shovel permits the breaking of concrete bags with no waste. From the shovel any material will flow smoothly and quickly through the hopper into the drum.

2.MIXING of Self Loading Concrete Mixer:
once in the drum, aggregates and concrete are perfectly mixed together with the self-pumped water from water tank. Mixing quality and therefore concrete quality is granted by the variable angel of logarithmic spiral.

3.DELIVERING of Self Loading Concrete Mixer:
No place is too difficult for our concrete mixer. The 4 wheel drive transmission, along with the ideal weight balance, allows to climb, fully loaded, over 30% gradients.

4.DISCHARGING of Self Loading Concrete Mixer:
The mixing unit is hydraulic slewing 270 degree for high discharge over 1.8m to the four sides of the vehicle.


Main Parts of Self Loading Concrete Mixer:
1,Ultimate tank
Loading capacity is larger for the same volume and the center of gravity is low for the same loading capacity.

2,Tank and Blade
Tank and blades are made of high-strength wear-resistant steel,with service life increased by 30%.

3,Driving System
As vehicle is equipped with four-wheel drive,it can be used for efficient and stable concrete production in harsh working conditions.

4,Weighting System
Ensuring that concrete meets the construction requirements and weighing pcision within ±3%.

5,Mixing System
Unique continuous trace design is used,with residual rate≤0.4% and a slump change at all stages of ≤5%.

6,Water Supply
Integrated control is used with one-inlet and multiple-outlet applied,convenient and fast.

7,Joymix
All hydraulic functions of shovel controlled by a single joystick.

8,Operation System
Longitudinal resistance-free design is used,to provided more flexible manipulation.

9,Loading shovel
Effective capacity per loading complete with hydraulic opening gate with bigger knife.


Spefication of Self Loading Concrete Mixer:

Name	Item	DWSL40		DWSL15
	Net	8300 KG		5430 KG
	Transmission	Full Hydraulic		Full Hydraulic
		4WD		4 WD
	Brake	Air Brake		Air Brake
	Chassis	Off-road		Off-road
	Loader bucket	capacity	0.6m3	capacity		0.4m3
		Control	Hydraulic	Control		Hydraulic
	Tilt angle	30%		20%
	Speed	High	0-25KM/H	High			0-25KM/H
		Low	0-9KM/H	Low			0-9KM/H
	Mini turning radius	6.5M/R		4.5M/R
Engine	Type	Cummins		Cummins
	Rated Power/RPM	85KW/2200RPM/125HP 2200RPM		55KW/2200RPM
	Max.Torque/RPM	460N.M/1400RPM		360N.M/1400RPM
	Cylinder	4		4
	Starter	Electric		Electric
	Cooling type	water cooling		water cooling
Maxing Drum	Drum capacity	3.85M3		1.5M3
	Bank Angle	16 °		16°
	Rotation Angle	17-21R/min		17-21R/min
Chute	Swing Angle	≥60°		≥60°
	Angle control	Hydraulic		Hydraulic
	Size	Long:176cm		Long:176cm
		Short:40cm		Short:40cm
Loader	Weighing model	computer control
		Concrete Standard		C15.C20.C25 C30
	Accuracy	concrete		≤±2%/time
		Relative Error		≤±3%/time
		water		≤±1%/time
		Additive		≤±1%/time
		Admixture		≤±2%/time
Control	One hydraulic 4 way stick				One hydraulic 4 way stick
Overall size	7500*2700*3380mm				6180x2430x2626mm
