Manufacturer Direct Trackless Railroad Transfer Vehicle for Production Line

BriefIntroduction----Railroad transfer vehicle
1--Manufacturer direct trackless railroad transfer vehicle for production line is a new style of halls and crane tracks
vehiclerunning on ground or floor for material handling,it is easy to turn 360 degrees at a minimum turning radius.
2--Our BEFANBY company is the professional manufacturer of direct trackless railroad transfer vehiclewith more than
15 years experience,we also can add the special device on the heavy goods vehicle, such as hydraulic lifting, sound and
alarm lights,electric scale,high temperature pvention,explosion pvention, etc.


Working principle----Railroad transfer vehicle
Manufacturer direct trackless railroad transfer vehicleis powered by storage battery,which is lead-acid battery pack.
The battery is installed in the vehicle, and supply DC electricity to the control system. It is consist of battery, motor,
reducer, vehicleframe, electric appliance, etc.There are the pendant control and wireless control two types of control
methods.

Advantages Show----Railroad transfer vehicle
·Powered by storage battery
·Factory history of 15 years
·Turning at a minimum radius
·Safety PU wheels for protection
·Running an unlimited way
·Operate easily
·Maintenance convenient

Application Show----Railroad transfer vehicle
This manufacturer direct trackless railroad transfer vehiclecan be widely applied in metallurgy, Machinery Fabrication,
Auto makers, Heavy Industrial, Light Industrial, Mold Maker, Construction Machinery maker, Shipyard, Port Cargo Yard,
Steel Transfer, Mining Transfer, Air and Space as well as Military industries and so on to transfer and handling equipment
or material from workshop to workshop or from bay to warehouse.

Parameter List----Railroad transfer vehicle

Model		BWP-2T	BWP-10T	BWP-20T	BWP-30T	BWP-50T	BWP-63T	BWP-150T
Rated load (T)		2	10	20	30	50	63	150
Table size	length(L)	2000	3600	4000	4500	5500	5600	10000
	Width(W)	1500	2000=	2200	2200	2500	2500	3000
	Height(H)	450	500	550	600	650	700	1200
Wheel base (mm)		1200	2600	2800	3200	4200	4300	7000
Rail Inner Gauge (mm)		1200	1435	1435	1435	1435	1435	2000
Wheel Diameter(mm)		Φ270	Φ300	Φ350	Φ400	Φ500	Φ600	Φ600
Wheel Quantity		4	4	4	4	4	4	8
Ground Clearance (mm)		50	50	50	50	50	75	75
Running speed (min)		0-25	0-25	0-20	0-20	0-20	0-20	0-18
Motor Power (Kw)		1	1.6	2.2	3.5	5	6.3	15
Battery Capacity(Ah)		180	160	180	250	330	400	600
Battery Voltage(V)		24	48	48	48	48	48	72
Running Time When Full Load		4.32	4.8	4	3.5	3.3	3	2.9
Running Distance for one Charge(Km)		6.5	7.2	4.8	4.2	4	3.6	3.2
Max Wheel Load (KN)		14.4	42.6	77.7	110.4	174	221.4	265.2
Reference Weight (t)		2.8	4.2	5.9	6.8	8	10.8	26.8

Characters Show----Railroad transfer vehicle
1,all ofrailroad transfer vehicleare equipped with state of the art safety features including safety lights, horns,
bumpers, dead man controls and mushroom type emergency stop buttons.
2,It can be used to transfer anything you imagine and working situations, such as steel coil, billets, bloom, ladle &
scrap, locomotive, vehicle, workpieces to painting shops or blasting room, etc;
3,We designed and added the special device on the railroad transfer vehicleto it can apply in the high temperature
and explosion working environment.


about Us
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltdis a collection of research, design, manufacture, installation
and after-sales service of electric handling bogie ,transfer carts as one of the professional manufacturing company,
which has a modernized management team and excellent staff.And our products gets CE, SASO,SGS,ISO certificate and
other 8 national patent, and our products have been exported to more than 40 countries and regions.


Our Certificate show


Our Customer show


Our production application show


Our supply scope show

Product Name	Model No.	Power Supply Mode	Load Capacity	Other Items	Usage
Rail Transfer Cart	KPD	Conductor Rail	Load range 1-300ton, can be customized per client demand	Running distance	Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc
Battery Powered Transfer Car	KPX	Battery		Using frequency
Motorized Transfer Trolley	KPJ	Cable Drum		Running distance
Busbar Powered Handling Cart	KPC	Busbar		Working shop
Towed Rail Trailer	KP	Tractor	1-100t	Working shop
Steerable Towed Car	BWT	Tractor	Load range 1-50t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded.	Working environment
Trackless Handling Machine	BWP	Battery		Working path

How to choose the suitable transfer vehicle?
All of our railroad transfer vehicleall customized as client's requirement, for choose the most suitable transfer vehicle,
please kindly providing the following information:
Transfer or handling what material/cargo?What capacity do you need?This transfer vehicleis running on rails or ground
(floor)?Your requirement for table size:length,width and height?How about the running distance?How many working
hours in per day?
