CURTIS 1221M programmable series motor controllers are designed to provide smooth, silent, cost-effective control of motor speed and torque. 1205M controllers are updated versions of the popular 1205 controllers, with the added functionality of being programmable-via the CURTIS Model1313-4331 Handheld Programmeror1314 PC Programming Station. This means the controllers can be tailored to the needs of specific applications. In addition to configuration flexibility, use of the programmer offers diagnostic and test capability.
CURTIS 1221M controllers are the ideal solution for a variety of electric vehicle applications, including industrial trucks, personnel carriers, material handing vehicles, golf cars, etc.
CURTIS Model: 1221M-6701Norminal Battery Voltage (Volts): 72V (default setting), 48V or 60V2 Minute Current Rating (amps): 5505Minute Current Rating(amps): 3751 Hour Current Rating (amps): 225Plug Braking (A2 Busbar): YesPWM operating frequency: 15.6 kHzElectrical isolation to heatsink (min.): 500 VACKSI input current (no contactors engaged):70 mA without programmer130 mA with programmerLogic input current: < 2 mAStatus LED output current (max.): < 2 mAThrottle Type: 0-5K Ω (default setting), 5K-0 Ω or 0-5V. Multiple throttle types are supported, for more details, please read carefully theCURTIS 1204M/05M/09M/21M ManualDimensions: L281xW180xH80 mmOperating ambient temperature range: -40°C to 50°CStorage ambient temperature range: -40°C to 85°CPackage environmental rating: ISTA 2A; electronics sealed to IP54Products Picture:
FAQ:
Q1. Can Ihave asample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.
Q6. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty for our products.
Q8: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%.
