50-60 CBM LNG Tank Truck Trailer,semitrailerforlng
Company information:
We're one professio
nal manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, co
ncrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to co
ntact us please.
Hot sale! 58.3 CBM LPG tank trailer
1. Origin: China
2. Packing: Nude
3. Min. Order: 1
4. Transportation: Shanghai
5. Certification: ISO
6. Scale: Heavy Duty
7. Components: Trailer Axles
8. Material: Steel
9. Type: Semi-Trailer
10. Volume: 58.3 Cbm
11. Alxe: Fuwa
12. Legs: 28 T
13. Design Temprature: 50 Degree
14. Design Pressure: 1.77MPa
15. Design Tech: Sad
16. Tanker Material: 16 Mnr
17. Nominal Diameter: Dn80
18. Cylinder Thickness: 14 Mm
19. Model: 10 Mm
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Q: How can we trust your company?
A: We are the official authority company by SINOTRUK, BEIBEN, SHACMAN & FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us. We also have cooperated several times with the third party named TCI from UK. They can inspect the trucks and trailers producing and shipping after getting your authorization.We are your reliable partner.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How a
bout warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
| Specification and producing standard |
| GB150-1998 Steel pssure vessels | |
| GB/T19905-2005 Liquefied gas truck | |
| Pressure vessel safety technology and inspection procedures | |
| Liquefied gas tanker safety monitoring procedures | |
| Tanker Essential Information |
| Dimensions(length*width*height) | 12370×2490×3970(MM) | |
| Estimated Tare Weight | 17700KG | |
| Payload | 22300KG | |
| Tank Volume | 58.3 CBM | |
| Total Weight | 40000KG | |
| Shell Of Tanker |
| Products | LPG, Butane , Propane | |
| Fluidproperty | flammable | |
| Design temperature | to 50 Degree centigrade | |
| Design pssure | 1.61MPa | |
| Corrosion allowance | 1.0mm | |
| Major materials of bearing pssure | Tanker body : Q345R , 12mm | |
| End plate : Q345R , 14mm | |
| Main Beam : Q345B | |
| Filling weight per volume | | |
| Maximum filling weight | | |
| Compartments | One | |
| Baffle inside the tank | 14-off Aluminium bolted plate , thickness is 5mm | |
| Shape | Cylindrical ; Ellipse head | |
| Detection |
| Heat treatment | Overall heat treatment in a furnace , 500 to 560Degree centigrade | |
| Flaw detection | 100% Flaw detection | |
| Hydrostatic test | 2.66MPa | |
| Magnaflux | Aim at welding place flaw detection can not cover | |
| Manhole (As customer's requirement ) |
| Quantity | 1 ; On top | |
| Safety Valve (As customer's requirement ) |
| Quantity | Two | |
| Location | On the top of tanker ; | |
| Type | only weld suitable flange | |
| Size | As customer's requirement | |
| Liquidometer (As customer's requirement ) |
| Quantity and Model | 1 | |
| Location | On left side of tanker | |
| Type | only weld suitable flange | |
| Size | As customer's requirement | |
| Valve and pipe Detail (As customer's requirement ) |
| Running System |
| Axles | 3 | 13 TON FUWA Axles | |
| Suspension system | 1 | FUWA Air suspension | |
| Wheel rim | 12 | 8.25*22.0 | |
| Tyre | 12 | Brand : Triangle,425/65R22.5 | |
| Kingpin | 1 | JOST 2", 2.5 | |
| Landing legs | 2 | JOST D200 single linkage,Gear type | |
| Pneumatic Brake System |
| Spring brake chamber | 6 | FUWA | |
| Air connector | 2 | FUWA | |
| Relay Valve | 1 | BRAND:WABCO | |
| ABS | 1 | KEMI ABS | |
| Electronical System |
| 7-Pin Socket | 1 | 24V 7-pin socket | |
| LED Lamp | 1 | All kinds of lamp | |
| Cable | 1 | Stander cable | |
| Accessories |
| Small Tool box | 1 | | |
| Wheel carrier | 1 | | |
| Fire extinguisher | 2 | With red box | |
| Cabinet | 1 | | |
| Plastic fender | 6 | | |
| Static conductive belt | 1 | | |
| Impeller blasting | 1 | Completely | |
| Paint:As customer requirements | |
