| Machinery Name | HOWO off-road miningdump truck |
| Driving type | 6×4 |
| Chassis No | ZZ5707S3641AJ |
| Cabin | HW7D 53° tiltable with A/C and sleeper |
| Brand | SINOTRUK HOWO |
| Overall dimensions (L×W×H)mm | 8334x3296x3770mm |
| Dump body dimensions (L×W×H)mm | 5600x3100x1800 |
| Wheel base(mm) | 3600+1500 |
| Tare weight(kg) | 12000kg |
| Rated loading weight (kg) | 58000kg |
| Front axle | HF12 Beam boxing type front axle |
| Rear axle | AC26(cast steel 2×26ton hub-reduction axle), cross-axle diff locks and inter-axle diff locks Speed ratio :10.47 |
| Axle load | 1x6960 2x10300 |
| Max.Driving speed(km/h) | 50 |
| Engine Type | 4 stroke, direct injection diesel engine, 6cylinder in-line with water cooling, turbo-charging &inter cooling |
| Engine Model | WD615.96E |
| Nominal powerkw/(r/min) | 276kw;375hp |
| Maximum torqueNm/(r/min) | 1500/1100~1600 |
| Emission standard | 9.726L |
| Gearbox | HW19710+HW70 |
| Clutch | Diaphragm spring clutch, diameter 430mm |
| Brakes | Service brake:dual circuit compssed air brake; Parking brake:spring enengy, compssed air operating on rear wheels Auxillary brake:engine exhaust valve brake |
| Steering gear | ZF8098,left, hydraulic steering with power assistance |
| Forward gears transmission ratio | 14.28;10.62;7.87;5.88;4.38;3.27;2.43;1.8;1.34;1 |
| Reverse ratio | 13.91;3.18 |
| Electric system | HOWO electric systemminus,24V, minus earth |
| Fuel tank(L) | 500L |
| Tire | 14.00-25NHS,1000±10kPa |
| front suspension | 1500mm;Half the elliptical leaf spring with shock absorber cavitation |
| Rear suspension | 1000mm;The overall balance shaft balance suspension, unilateral inclined outfit 4riding bolt |
| Color | Red,white,green,yellow |
| Q1: Iwant the front two tires are bias tires and the rear 9tires are radial tires, is it OK ? |
| A: We can make the tires as your requirement to suit your country's need. |
| Q2: What about your products quality ? |
| A: Quality is our culture! "Our factory has advanced production technology and management team! We always attach great importance to quality controlling from the very beginning! |
| Q3: Can ihave samples of this type of flatbed semi trailer to test the quality ? |
| A: Yes, you can buy any samples to test the quality,our MOQ is 1unit. |
| Q4: What others you can do ? |
| A: According to your order, we will provide the best price and quality trucks and trailers. And we are well capable in offering overseas after-sales service. Besides, we also provide rational packing and shipping program,let shipment save money and security. |
| Q5: How to guarantee customers get the goods smoothly after they pay ? |
| A: Don't worry, dear. We have been in this field for 10 years, we will send you production photos once in awhile, and we will help you to book the latest ship. |
| Q6:What's the delivery time ? |
| A: The delivery time is within 15-30 working days after receiving your advance payment. |
| Q7:Can you supply some quick-wear truck or semi trailer parts ? |
| A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balancebeam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads,brake pan, bearings etc. |
