Overview
| Quick Details |
| Wattage:200 - 250w | Voltage:36V | Power Supply: Lithium Battery |
| Wheel Size: 12" | Motor: Brushless | Certification: CE |
| frame Material: Aluminum Alloy | Foldable: Yes | Max Speed: 20KM/H |
| Range per Power: 31 - 50 km | Place of Origin: Changzhou, China (Mainland) |
Description
1. Fast and easy folding without tools
2. Aluminium Alloy and Magnesium Alloy
3. Lithium battery, 800 times life battery
| Motor | 350W High Speed Brushless Gear motor | frame | Aluminum alloy |
| Controller | 36V controller | Tyres | 12"×2.125", |
| Pedaling Run/Pedaling-Electric Assist Run | Rim | Aluminum alloy |
| Option | Pure Electric Run Model | Spokes | 13g steel |
| Overload protection ,Low voltage protection | Brakes | front /rear disc |
| Battery | 36V 9Ah lithium battery | throttle | twist intelligent speed controll and PAS Performance. |
| Charger | 100-240VAC50-60HZ,2A amps smart charger | Gears | single gear |
| Charge time 4-6 hours | Traction | front wheel drive |
| Max Speed | 20km/h | Handle bars | Alloy |
| Range | e-bike mode 25-38km, | Chainguard | ST14 |
| Pedaling-Electric mode 45-55km | Mudguard | ST14 |
| Load capacity | 110kg | Chainwheel | Steel 36t T,steel crank |
| N.W./G.W. | 18.5/23KGS | Chain | Rust resistant chain |
| folding size | 610 × 275 × 810mm | Stander | Steel central stander |
| Product Size | 1800×1100×560 mm | unfold size | 1260 × 550 × 1090mm |
| Carton Size | 620×280×835 mm | Saddle | GEL Cruiser saddle |
| Capability | 186pcs/20Gp 478pcs/40HQ | Seat Post | Steel with suspension |
Packing details
Operation demo
Warranty
| 1.frame:2 years quality warranty. |
| 2.Battery: 24months quality guarantee for Li-ion battery. |
| 3.Electric motor: we provide as long as 24 months quality warranty. |
| 4.Charger/Controller: 12 months quality warranty. |
| 5.The other electric parts: 6 months quality warranty. |
Our service
| If you order thefull container,we can provide: |
| *1% free spare parts. *Your logo design is free. *We have a discount. |
| Pre-Sales Service: |
*Inquiry and consulting support.
*Sample testing support.
*Visit our company. |
| After-Sales Service: |
*frame:2 years quality warranty.
*Battery:2 years quality warranty for li-ion battery.
*Motor:2 years quality warranty.
*Charger/Controller:2 years quality warranty. |
FAQ
Q: CAN I GET SOME SAMPLE?
A:Yes, sample order is available for quality and market test.
Q: WHICHSHIPMENTMETHODISTHEBESTCHOICE?
A:If you want to arrange by Sea freight for your sample order,
of course,the sea freight is cheaper. But there will be some
cost from your customs. Then the total cost will be next to
Expss Freight. But the Sea Freight will waste more time.
Eventhere are some troubles from your customs. So we
suggest the Expss Freight.
Q: WHAT'STHEDELIVERYTIME?
A:For sample order, if we have stock, there is o
nly need a
bout 1
week. If we do not have any stock, there will need a
bout 25-35days.
For wholesaler order, usually we can make a delivery within 4 weeks
after get your deposit, if you do not have any special request.
Q: CAN I MAKE LOGO ON OUR SAMPLES?
A:Yes,depends on qty we will have an extra cost.
Q: HOW DOES YOUR FACTORYDO REGARDINGTHE QUALITY CONTROL?
A:Quality is priority.
We always attach great im
portance to quality co
ntrol from the very
beginning to the end of the production. Every product will be fully
assembled and carefully tested before packing and shipping.
Enjoy your life!
For details feel free to co
ntact us!
